Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in PANEL FRONT ASSY.
2. HEATSINK MAIN ASSY
(1) Disconnect the connector wires and FFC Cable.
Picture C
Picture D
Proceeding : CABINET TOP → HEATSINK MAIN ASSY
Top view
CP110 CP111
CP701
CP107
Cord holder : Loose
Cord holder : Loose
FFC Cable
