9
2. HDMI UNIT
(1) Remove the screws.
(2) Disconnect the connector wire and FFC cable.
TOP
COVER
HDMI UNIT
→
Proceeding :
Direction of photograph: A
CN12FFC cable
HDMI UNIT
