3. INPUT UNIT
(1) Remove the screws.
(2) Disconnect the connector wires and FFC cables, then remove the screws.
TOP
COVER
HDMI UNIT
→
INPUT UNIT
→
Proceeding :
Direction of photograph: A
CN42
CN71 CN43
FFC cable
FFC cable
INPUT UNIT
