Page #27 background image
27
27DN-S5000
DescriptionPin No.
Pin Name
Type
43 CE O Center Error Signal Output. Center error output reference to VCI
34 NEVO O SIGO Bottom Envelope Output. Bottom envelope for mirror detection
37 DFT O
Defect Output. Pseudo CMOS output. When a defect is detected, the DFT output goes high. Also
the servo AGC output can be monitored at this pin, when CAR bits 7-4 are ‘0011’
29 MIRR O Mirror Detect Output. Mirror Detect comparator output. Pseudo CMOS output
36 PI O
Pull-in Signal Output. The summing signal output of A, B, C, D or PD1, PD2 for mirror detection.
Reference to VCI
22 DVDLD O APC output. DVD APC output pin to control the laser power
24 CDLD O APC output. CD APC output pin to control the laser power
56 BYP I/O The RF AGC integration capacitor CBYP, is connected between BYP and VPA
9 CP I/O
Differential Phase tracking LPF pin. An external capacitance is connected between this pin and
the CN pin
10 CN I/O
Differential Phase tracking LPF pin. An external capacitance is connected between this pin and
the CP pin
45 LCP Center Error LPF pin. An external capacitance is connected between this pin and the LCN pin
44 LCN Center Error LPF pin. An external capacitance is connected between this pin and the LCP pin
30 MP MIRR signal Peak hold pin. An external capacitance is connected to between this pin and VPB
31 MB MIRR signal Bottom hold pin. An external capacitance is connected to between this pin and VPB
39 MEV Sigo Bottom Envelope pin. An external capacitance is connected to between this pin and VPB
17 CDTE CD Tracking. E-F Opamp output for feedback
38 TPH PI Top Hold pin. An external capacitance is connected to between this pin and VPB
26 VC
Reference Voltage output. This pin provides the internal DC bias reference voltage (+2.5V lix).
Output Impedance is less than 50ohms
27
VCI Reference Voltage input. DC bias voltage input for the servo input reference
18 VCI2 Reference Voltage input. DC bias voltage input for the servo input reference
55 RX
Reference Resistor Input. An external 8.2kohm, 1% resistor is connected from this pin to ground
to establish a precise PTAT (proportional to absolute temperature) reference current for the filter
33 MLPF MIRR signal LPF pin. An external capacitance is connected between this pin and VPB
19 NC No Connect
48 SDEN I
Serial Data Enable. Serial Enable CMOS input. A high level input enable the serial port (Not to be
left open)
47 SDATA I/O
Serial Data. Serial data bi-directional CMOS pin. NRZ programming data for the internal registers
is applied to this input ( Not to be left open)
46 SCLK I
Serial Clock. Serial Clock CMOS input. The clock applied to this pin is synchronized with the data
applied to SDATA (Not to be left open)
58 VPA Power. Power supply pin for the RF block and serial port
28 VPB Power. Power supply pin for the servo block
50 VNA Ground. Ground pin for the RF block and serial port
20 VNB Ground. Ground pin for the servo bolck
