Denon DN-S5000 Service Manual

43
43DN-S5000
GU-3483/3423A PANEL P.W.B. UNIT ASS'
Y
Ref. No. Part No. Part Name Remarks New Ref. No. Part No. Part Name Remarks New
R114 247 2005 990 RM73B--241JT
R115 247 2005 945 RM73B--151JT
IC101 262 3048 007 ML9207-01GP R116 247 2005 990 RM73B--241JT
IC102 262 3227 006 TMP86CM47U-4K73(PN) R117 247 2005 945 RM73B--151JT
IC103 262 2745 903 BU2090F(E2) R118 247 2005 990 RM73B--241JT
IC201 262 2745 903 BU2090F(E2) R119 247 2005 945 RM73B--151JT
IC251,252 269 0203 008 GP1A70R R120 247 2005 990 RM73B--241JT
IC901 265 0112 003 STR-F6674 R121,122 247 2018 903 RM73B--0R0KT
IC902 262 3047 008 PC123 Y-22 R123 247 2006 902 RM73B--331JT (1608)
IC903 263 1113 005 SE005N R124,125 247 2005 987 RM73B--221JT
R126 247 2005 945 RM73B--151JT
TR101,102 272 0081 909 2SB766S(TAPE) R127 247 2005 990 RM73B--241JT
R128 247 2005 945 RM73B--151JT
D101-104 276 0559 909 DAP202KT146 R129 247 2005 990 RM73B--241JT
D901 276 0767 005 RBV-406 R130 247 2005 945 RM73B--151JT
D902 276 0730 906 AG01ZT (V1) R131 247 2005 990 RM73B--241JT
D904-906 276 0730 906 AG01ZT (V1) R132 247 2005 945 RM73B--151JT
D908 276 0784 004 FMB-G14 * R133 247 2005 990 RM73B--241JT
D909 276 0786 002 RN1Z * R134 247 2003 947 RM73B--220JT
D910 276 0787 001 RN2Z * R135 247 2006 944 RM73B--391JT
D911 276 0788 000 RN3Z * R136 247 2007 927 RM73B--821JT
D912 276 0769 003 RK-44 R139-142 247 2007 943 RM73B--102JT
D913 276 0785 906 AW04 * R143-148 247 2004 904 RM73B--390JT
R149 247 2007 901 RM73B--681JT
ZD901 276 0760 989 MTZJ7.5B T77 R152-155 247 2009 983 RM73B--103JT
ZD902 276 0760 905 MTZJ3.6B T77 R156,157 247 2018 903 RM73B--0R0KT
R158 247 2011 942 RM73B--473JT
LD101 393 9605 900 SEL6427EP(TP5) R159,160 247 2009 983 RM73B--103JT
LD102,103 393 9604 901 SEL6227S(TP5) R161-163 247 2009 983 RM73B--103JT for E3
LD104 393 9606 909 SEL6927A(TP5) R161-163 247 2007 943 RM73B--102JT for E2
LD105,106 393 9608 907 SLR342MC(TB7) R164 247 2011 942 RM73B--473JT
LD107-110 393 9607 908 SLR342VC(TB7) R165 247 2009 983 RM73B--103JT
LD111,112 393 9608 907 SLR342MC(TB7) R166-168 247 2011 942 RM73B--473JT
LD113 393 9605 900 SEL6427EP(TP5) R169-172 247 2003 947 RM73B--220JT
LD114,115 393 9604 901 SEL6227S(TP5) R173-175 247 2007 943 RM73B--102JT
LD116 393 9606 909 SEL6927A(TP5) R176-178 247 2009 983 RM73B--103JT for E3
LD117-120 393 9620 901 SMLU79423C(TP15) R176-178 247 2009 983 RM73B--103JT for E2
LD126-129 393 9620 901 SMLU79423C(TP15) R179 247 2011 942 RM73B--473JT for E3
LD201 393 9608 907 SLR342MC(TB7) R179 247 2009 983 RM73B--103JT for E2
LD202-204 393 9610 908 SLR342YC(TB7) R180,181 247 2009 983 RM73B--103JT for E3
LD205 393 9605 900 SEL6427EP(TP5) R180,181 247 2009 983 RM73B--103JT for E2
LD206 393 9604 901 SEL6227S(TP5) R182 247 2018 903 RM73B--0R0KT
LD207 393 9605 900 SEL6427EP(TP5) R183,184 247 2012 925 RM73B--104JT
LD209 393 9543 910 SLR-325MC (GRN) TAPE R187 247 2011 942 RM73B--473JT
LD210 393 9543 923 SLR-325DC (ORG) TAPE R190 247 2011 942 RM73B--473JT
LD211 393 9543 907 SLR-325VC (RED) TAPE R201-204 247 2005 987 RM73B--221JT
LD212 393 9605 900 SEL6427EP(TP5) R205 247 2007 901 RM73B--681JT
LD213 393 9604 901 SEL6227S(TP5) R206,207 247 2006 902 RM73B--331JT (1608)
LD214 393 9605 900 SEL6427EP(TP5) R208,209 247 2005 990 RM73B--241JT
LD215,216 393 9625 003 LNW901BZFZ(BLUE) R210-212 247 2005 945 RM73B--151JT
LD251,252 393 9604 901 SEL6227S(TP5) R214 247 2005 945 RM73B--151JT
R216 247 2005 961 RM73B--181JT
TH901 279 0044 002 NTH11D8R0LA R219 247 2006 944 RM73B--391JT
R220 247 2006 915 RM73B--271JT
R221 247 2005 961 RM73B--181JT
R222 247 2005 945 RM73B--151JT
R223 247 2007 901 RM73B--681JT
R251-255 247 2009 983 RM73B--103JT
R101,102 247 2005 990 RM73B--241JT R258 247 2005 974 RM73B--201JT
R103-105 247 2006 902 RM73B--331JT (1608) R260 247 2005 974 RM73B--201JT
R106 247 2007 927 RM73B--821JT R261,262 247 2005 987 RM73B--221JT
R107 247 2006 944 RM73B--391JT R301-325 247 2018 903 RM73B--0R0KT
R108,109 247 2005 987 RM73B--221JT R329-343 247 2018 903 RM73B--0R0KT
R110-112 247 2006 902 RM73B--331JT (1608) R345-357 247 2018 903 RM73B--0R0KT
R113 247 2005 945 RM73B--151JT R363-406 247 2018 903 RM73B--0R0KT
