48
48DN-S5000
PARTS LIST OF CD DRIVE UNIT ( FG-5000 )
Ref. No. Part No. Part Name Remarks Q'ty New
1 9KA 2A49 6A
9KC 2G03 9A
DRIVE UNIT
TD-S202H2D (FG5000MECHA)ASS'Y
1*
2 GU-3414 CD-ROM PWB UNIT 1
3 415 0900 001 PROTECT SHEET 4 *
5 412 4997 008 DRIVE BRACKET 1 *
7 HEAT SINK 1
8
9 146 2296 309 DISC GUIDE 1 *
10 415 0897 004 BLIND SHEET 1 *
11 415 0898 003 FIX PLATE 1 *
12 144 2816 107 DRIVE PANEL 1 *
15 102 0657 018 DRIVE COVER 1 *
16 513 3797 007 CONNECT LABEL 1
18 513 3826 004 E2 LASER CAUTION 1
58 441 1972 105 MAIN BASE ASS'Y 1 *
58-1 MAIN BASE 1
58-2 PWB SHAFT 2
58-3 PWB SHAFT 2
4 471 3203 022 2.6X6 CBS-B 4
6 473 7001 035 2.6X6 CBTS (S)-Z 4
13 475 1178 009 3W-B 4
14 471 9050 033 3X8 FHHS MFZNII-B 4
19 473 7002 005 3X6 CBTS(S)-Z 4
SCREWS
-
HEAT PAD
3
To Next Page
