CONRTOL_1
1
CONRTOL 1 PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only
olumn Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D106,107 941209000470S ESD DIODE(RSB6.8S 150mW.6.8V EMD2 ROHM) 414-DJ1100G-207 2
D108-152 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 45
D153-156 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 4 *
D157,158 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D159-176 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 18 *
D177,178 941176100190P
LED(AMBER,∮3,TAPING)
410-6K2-436 2 *
D179,180 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D181 nsp TVS DIODE(SMAJ6.0A,400W,6.0V,DO-214AC) 414-UDJ200-284 1
D182-206 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 25
D207,208 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D209,210 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D211-216 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 6 *
D217,218 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D219,220 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D221-228 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 8 *
D229,230 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D231-237 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 7 *
D238 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D238 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D239 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D239 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D240 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 1 *
D241,242 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D243 941176100190P
LED(AMBER,∮3,TAPING)
410-6K2-436 1 *
D244,245 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D246 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D246 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D247 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D247 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D248-251 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 4 *
D252 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D252 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D253 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D253 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1
*
D254,255 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D256,257 941176100190P
LED(AMBER,∮3,TAPING)
410-6K2-436 2
*
D258 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D258 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D259 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D259 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D260-262 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 3
D263-268 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 6 *
D269,270 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D271,272 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D273,274 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D275-278 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 4 *
D279 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D279 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D280 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D280 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D281 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 1 *
D282 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D282 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D283 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D283 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D284 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D284 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D285 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D285 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D286 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D286 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D287 941176100200P
LED(GEEN/ORANGE,∮3)
410-6K2-432 1 *
D287 nsp LED HOLDER(LED3X-3A) 504-6K2-303 1 *
D288-308 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 21
IC100 941243101970P CONTROL IC ASS'Y 704-6K2-A620 1 *
nsp IC(STM8S207MBT6B,LQFP-80) 417-EN2000-1039 1 *
IC101,102 941236101640P IC(74HCT595) 417-6K2-1141 2 *
IC103,104 941239004980P IC(74HC4052D/74HC4052DT,SMD) 417-QSPAND-432 2
IC105 941248102450P IC(EN25F1-100GIPTR) 417-DDJLE-1084 1 *
IC106 941243004220P IC(PIC16F616-I/SL,SOIC-16) 417-RMP3-936 1
IC107 941236101640P IC(74HCT595) 417-6K2-1141 1 *
IC108-110 941239004980P IC(74HC4052D/74HC4052DT,SMD) 417-QSPAND-432 3
IC111 941243004220P IC(PIC16F616-I/SL,SOIC-16) 417-RMP3-936 1
Q100 941214004530P CHIP TRANSISTOR(2SD1757KT146R,SMT3) 416-MC6000-374 1
Q101-107 941212004520P CHIP TRANSISTOR(2SB1424T100R) 416-MC6000-375 7
Q108-120 941214004530P CHIP TRANSISTOR(2SD1757KT146R,SMT3) 416-MC6000-374 13
ZD100-103 nsp ESD DIODE(EDZCTE61 6.8B,150MW/6.93V,EMD2 414-RMP3-285 4
RESISTOR GROUP
R100,101 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 2
R102,103 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP) 412-CDVD2001-530 2
R104-108 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP) 412-CDVD2001-521 5
R109 nsp CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-540 1
R110-112 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP) 412-CDVD2001-530 3
R113-117 nsp CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-540 5
R118-127 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP) 412-CDVD2001-521 10
R128 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R129 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R130-133 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP) 412-CDVD2001-530 4
R134 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP) 412-CDVD2001-523 1
R135-141 nsp CHIP RESISTOR(680 OHM,1/10W,J,TP ,50V) 412-900-1060 7
R142,143 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 2
R144 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ) 412-CDVD2001-532 1
R145 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R146 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ) 412-CDVD2001-532 1
R147-150 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 4
R151 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
