MAIN
6
MAIN PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed belo
olumn Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1,2 941204500330P DIODE(SM5819A,1A,40V,DO-214AC) 414-007USB-148 2 *
D427 nsp FIXED PLATE 300-4500-2010A 1
D427 nsp FIXED PLATE 300-4500-2010A 1
D900 941204500340P SCHOTTKY BARRIER DIODE(SM5817A) 414-COMBO-355 1 *
D901-904 941209000470S ESD DIODE(RSB6.8S 150mW.6.8V EMD2 ROHM) 414-DJ1100G-207 4
D905-907 nsp TVS DIODE(SMAJ6.0A,400W,6.0V,DO-214AC) 414-UDJ200-284 3
IC1,2 941239100890P IC(SOP8,TPS54232) 417-PDJ33-1045 2
IC900 941231004770P IC(BD12KA5FP,TO252-3) 417-IQ2UM-1004 1
IC901 941239004760P IC(TUSB3200ACPAH,PQFP52,) 417-DAIA-711 1
IC902 941245004440P IC(DSP56724,LQFP-44) 417-IQ2UM-941 1
Q1 941211500250P CHIP TRANSISTOR(PMN3603) 416-6K2-401 1 *
Q900 941216004830P CHIP TRANSISTOR(DTC124TKA) 416-DFX1-201 1
ZD900 nsp ESD DIODE(EDZCTE61 6.8B,150MW/6.93V,EMD2) 414-RMP3-285 1
RESISTOR GROUP
R1 nsp CHIP RESISTOR(8.2K,1/10W,F,TP 0603,50V) 412-900-987 1
R2 nsp CIHP RESISTOR(43KOHM,1/10W,F,TP 0603,50V 412-900-996 1
R3 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ) 412-CDVD2001-532 1
R4 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R5 nsp CHIP RESISTOR(68KΩ,1/10W,J,TP 0603,50V) 412-U5000-1140 1
R6 nsp CHIP RESISTOR(1.5K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-550 1
R7 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP) 412-CDVD2001-523 1
R8 nsp CHIP RESISTOR(39K OHM,1/10W,0603,J,TP ) 412-007USB-706 1
R900,901 nsp CHIP RESISTOR(3.3K OHM,1/10W, 0603,J,TP) 412-007USB-699 2
R902 nsp CHIP RESISTOR(7.5K OHM,1/10W,J,TP 0603,50V) 412-G9900-1196 1
R903 nsp CHIP RESISTOR(1 OHM,1/10W,0603,J, TP ,50V) 412-007USB-695 1
R904 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP) 412-CDVD2001-521 1
R905,906 nsp CHIP RESISTOR(33OHM,1/10W,J,TP 0603,50V) 412-007USB-782 2
R907,908 nsp CHIP RESISTOR(1.5K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-550 2
R910 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R912 nsp CHIP RESISTOR(3.09K OHM,1/10W,F,TP 0603) 412-PDJ1-1291 1
R914-916 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 3
R918 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R919 nsp CHIP RESISTOR(820OHM,1/10W,J,TP 0603,50V 412-900-1010 1
R920-923 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP) 412-CDVD2001-530 4
R924-927 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 4
R929,930 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 2
R936 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R938 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R941,942 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 2
R943,944 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 2
R945-948 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP) 412-CDVD2001-530 4
R949,950 nsp CHIP RESISTOR((47 OHM,1/10W,0603M,J,TP ) 412-007USB-697 2
R951-953 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 3
R954 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP) 412-CDVD2001-521 1
R955-961 nsp CHIP RESISTOR((47 OHM,1/10W,0603M,J,TP ) 412-007USB-697 7
R962,963 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 2
R965 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R967 nsp CHIP RESISTOR(1M OHM,1/10W,0603,J,TP ,50V) 412-CDVD2001-546 1
R969 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R970,971 nsp CHIP RESISTOR(3.3K OHM,1/10W, 0603,J,TP) 412-007USB-699 2
CAPACIITORS GROUP
C1 nsp CHIP CAPACITOR(10uF/25V,1206 TAP,Y5V,Z) 413-MC6000-1180 1
C10 nsp S.C. CHIP CAP(390pF,J,50V,NPO,TAPING,0603) 413-CR701-5175 1
C11,12 nsp CHIP CAPACITOR(22uF/16V,Z,Y5V) 413-AMW4-1066 2
C13,14 nsp CHIP CAPACITOR(33pF/50V,J,0603 TAP,NPO) 413-900-926 2
C15,16 nsp CHIP CAPACITOR(22uF/16V,Z,Y5V) 413-AMW4-1066 2
C17 nsp ELEC. CAPACITOR(330uF/10V,M,6.3*11,TAPING) 413-COMBO-1257 1
C18 nsp
ELEC. CAPACITOR(470uF/10V,M, 105℃,TAPING)
413-HT8015-169 1
C19 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C2 nsp CHIP CAPACITOR(10uF/25V,1206 TAP,Y5V,Z) 413-MC6000-1180 1
C20 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C21 nsp
ELEC. CAPACITOR(2200uF/25V,M, 105℃,BULK)
413-HT8023K-188 1
C22 nsp CHIP CAPACITOR(4.7uF/25V,1206 TAP,Y5V,Z) 413-MC6000-1179 1
C3,4 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C5,6 nsp CHIP CAPACITOR(0.015uF/50V,M,0603 TAP,Y5V) 413-M207-1090 2
C7,8 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C9 nsp S.C. CHIP CAP(390pF,J,50V,NPO,TAPING,0603) 413-CR701-5175 1
C900,901 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C902,903 00D9587032709
ELEC. CAPACITOR(220uF/10V,M,105℃,TAPING)
413-HT801K-192 2
C904-912 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 9
C913,914 nsp CHIP CAPACITOR(10uF/10V,Z,1206 TAP,Y5V) 413-007USB-796 2
C915,916 nsp CHIP CAPACITOR(33pF/50V,J,0603 TAP,NPO) 413-900-926 2
C917 nsp CHIP CAPACITOR(100pF/50V,J,0603 TAP,NPO) 413-DCM280-767 1
C918 nsp CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R) 413-DCM280-768 1
C919-940 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 22
C941,942 nsp CHIP CAPACITOR(33pF/50V,J,0603 TAP,NPO) 413-900-926 2
C943,944 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889 2
C949-951 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 3
OTHER PARTS GROUP
CN102TOCB1\\CN102
941644101900P 24P 1.0 FFC SOCKET(SMD90°) 404-RECYCLE-3555 1 *
CN1TOPCB\W\1 nsp 6P SOCKET(CKM2501WV-6P 180°WHITE) 404-HV3500K-630A 1
CN801TOIOPC\B\CN8
941644101920P 20P 1.0 FFC SOCKET(SMD90°) 404-DJM250-3613 1 *
! F1 941652500360P CHIP FUSE(1A/32V,0603 TYPE,SMD) 422-HC1000-108 1 *
! F2 941652500370P CHIP FUSE(1.5A,63V,1206 TYPE) 422-3BPM-069 1 *
! F3 941652004870P CHIP FUSE(2.5A/63V,1206,SMD) 422-MC6000-110 1
JK1 941642002880S
DC POWER JACK(∮2.5,DJ-0702B-025)
420-CDMIX1-078 1
JK900 nsp GROUND PLATE 300-S1-2069 1
JK900 nsp USB JACK(319BF0A0LBN,B/F 90) 420-S1-377 1
L1-5 nsp BEAD CORE(A70512003, T-26mm) 415-HV3500K-090 5
L6,7 nsp INDUCTANCE(15uH) 415-IM-302 2
L8 nsp POWER CHOKE(22uH,1.11A) 415-MC6000-356 1
L900,901 nsp POWER CHOKE(22uH,1.11A) 415-MC6000-356 2
L902 941119000490S TDK COMMON MODE FILTERS(ACM2012-900-2P-T) 415-FU800-305 1
SW1 941661002570S POWER SWICH(PSK 1-2B-0) 403-VP9812-162 1
SW900 941664005030P SLIDE SW(SSSF113NA3-HF,L=6) 403-IM-314 1
X900 941141101070P CRYSTAL(HC-49S,6MHz,11.5*4.65MM) 427-S1-143 1 *
