IO
8
IO PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D40,41 00D9410046804 DIODE(1N4002(GW)-TP/1N4002TA,1A/100V) 414-DV300-5014 2
D42 941202500790P CHIP ZENER DIODE 414-DJM4000-331 1 *
D43 nsp DIODE(1N5819(GW)/1N5819,TAPING 52mm) 414-DFX1-144 1
D44 nsp CHIP DIODE(TFZ-8.2B,1/2W) 414-6K2-361 1
D46 nsp CHIP DIODE(TFZ-6.2B,1/2W) 414-6K2-354 1
D47 nsp DIODE(1N5819(GW)/1N5819,TAPING 52mm) 414-DFX1-144 1
D48,49 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 2
D50 941209000470S ESD DIODE(RSB6.8S 150mW.6.8V EMD2 ROHM) 414-DJ1100G-207 1
D51-53 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 3
D500 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 1
D503 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 1
D514-529 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 16
Q40 941211500280P TRANSISTOR(NPN KTC3228Y TO-92L TP) 416-XM910-270 1 *
Q41 941212500200S TRANSISTOR(2SA2127-AE) 416-UJ300KM-386 1
Q42,43 00D9410046309 TRANSISTOR(TR 2SA1037AKR SMT3) 416-CDN88-045 2
Q45 941213500220P TRANSISTOR(TR DTC124EKAT146 SMT3) 416-CDN88-044 1
Q46 90M-HT400500R TRANSISTOR(2SD1207T-AE) 416-1360S-016 1
Q500 00D9587057506 TRANSISTOR(DTA124EKA-T146,SMT3) 416-CTB200-178 1
Q501,502 941214500170P TRANSISTOR(2SD2704KT146,SMT3) 416-3000-378 2
Q503 00D9587057506 TRANSISTOR(DTA124EKA-T146,SMT3) 416-CTB200-178 1
Q504,505 941214500170P TRANSISTOR(2SD2704KT146,SMT3) 416-3000-378 2
Q506-509 941211500240P CHIP TRANSISTOR(2SA1312BL) 416-6K2-409 4 *
Q512,513 941214500170P TRANSISTOR(2SD2704KT146,SMT3) 416-3000-378 2
Q518-521 941214500170P TRANSISTOR(2SD2704KT146,SMT3) 416-3000-378 4
Q526-529 941214500170P TRANSISTOR(2SD2704KT146,SMT3) 416-3000-378 4
Q542,543 00D9587057409 CHIP TRANSISTOR(2SC2412KT146R) 416-CDN88-051 2
Q544,545 00D9410046309 TRANSISTOR(TR 2SA1037AKR SMT3) 416-CDN88-045 2
Q546,547 00D9580055107 TRANSISTOR(2SA1015-GR T-92 TAPING) 416-KE200X-021 2
Q548,549 00D9587057603 TRANSISTORS(2SC1815-GR-AP ) 416-DJ1900-023 2
Q550-553 941214500170P TRANSISTOR(2SD2704KT146,SMT3) 416-3000-378 4
U40 941231101720P IC(BU33TD3WG-TR) 417-COMBO-1091 1 *
U42 00D9410045601 IC(BD4745G-TR,SMP5) 417-HDJ2000-503 1
U500-510 941232100430P IC(NJM8080G) 417-6K2-1142 11 *
U512 941232100430P
IC(NJM8080G)
417-6K2-1142
1
*
U513,514 00D9587035803 IC(NJM-2068M-TE2,SOP8) 417-M5-582 2
U515 941232100430P IC(NJM8080G) 417-6K2-1142 1 *
U516 941231101710P IC(NJM79L09UA) 417-6K2-1154 1 *
U741 941239100890P IC(SOP8,TPS54232) 417-PDJ33-1045 1
U750-752 941239101210P IC(CS5341) 417-6K2-1143 3 *
U753,754 941239101060S IC(PCM1803ADB,SSOP-20) 417-IQ2UM-940 2
U755,756 941239101230P IC(CS4351-CZZ/CZZR,TSSOP) 417-UDJ303-1099 2 *
U758 941239100630P IC(CD74HC4050M96,SOIC-16) 417-IQ2UM-970A 1
U759 941239101230P IC(CS4351-CZZ/CZZR,TSSOP) 417-UDJ303-1099 1 *
RESISTOR GROUP
R40 nsp CARBON FILM RESISTOR(1.5K OHM,1/4W,J,T-2 412-HT7016-229 1
R41,42 nsp CARBON FILM RESISTOR(1.2K OHM,1/4W,J,T-5 412-HT8015-203 2
R43,44 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 2
R45 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R47 nsp CHIP RESISTOR(1.5K OHM,1/10W,B,TP 0603) 412-6000-1521 1
R48 nsp CHIP RESISTOR(21K OHM,1/10W,F,TP 0603,50V) 412-COMBO-1566 1
R49 nsp CHIP RESISTOR(6.8K,1/10W,J,0603,50V) 412-900-985 1
R50 nsp CHIP RESISTOR(5.6K OHM,1/10W,0603,J,TP ) 412-007USB-701 1
R51 nsp CHIP RESISTOR(6.8K,1/10W,J,0603,50V) 412-900-985 1
R52 nsp CHIP RESISTOR(0 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-552 1
R54 nsp CHIP RESISTOR(51KOHM,1/10W,J,TP 0603,50V 412-900-977 1
R55 nsp CHIP RESISTOR(2.2K OHM,1/10W,0603,J,TP ) 412-007USB-693 1
R56 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP) 412-CDVD2001-523 1
R57 nsp CHIP RESISTOR(0 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-552 1
R58 nsp CARBON FILM RESISTOR(390ohm,1W,J) 412-6K2-1669 1
R59 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 1
R60 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R61 nsp CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-540 1
R500,501 nsp CHIP RESISTOR(7.5KOHM,D,TP 0603) 412-6K2-1662 2
R502,503 nsp CHIP RESISTOR(1KOHM,D,TP 0603) 412-6K2-1661 2
R504,505 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ) 412-CDVD2001-532 2
R506,507 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 2
R508 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R509 nsp CHIP RESISTOR(51KOHM,1/10W,J,TP 0603,50V 412-900-977 1
R510,511 nsp CHIP RESISTOR(1KOHM,D,TP 0603) 412-6K2-1661 2
R512,513 nsp CHIP RESISTOR(270OHM,D,TP 0603) 412-6K2-1660 2
R514,515 nsp CHIP RESISTOR(270KOHM,D,TP 0603) 412-6K2-1668 2
R516,517 nsp CHIP RESISTOR(22K OHM,1/10W,0603,D,TP ) 412-500C-1559 2
R518,519 941129500890P CHIP RESISTOR(33K OHM,1/10W,0.5%,TP 0603) 412-MC2-1551 2
R520,521 nsp CHIP RESISTOR(4.7K OHM,1/10W,0.5%,TP 0603) 412-MC2-1547 2
R522,523 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,D,TP) 412-500C-1558 2
R524,525 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ) 412-CDVD2001-532 2
R526,527 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 2
R528 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R529 nsp CHIP RESISTOR(51KOHM,1/10W,J,TP 0603,50V 412-900-977 1
R530,531 nsp CHIP RESISTOR(1KOHM,D,TP 0603) 412-6K2-1661 2
R532,533 nsp CHIP RESISTOR(270OHM,D,TP 0603) 412-6K2-1660 2
R534,535 nsp CHIP RESISTOR(270KOHM,D,TP 0603) 412-6K2-1668 2
R536,537 nsp CHIP RESISTOR(22K OHM,1/10W,0603,D,TP ) 412-500C-1559 2
R538,539 941129500890P CHIP RESISTOR(33K OHM,1/10W,0.5%,TP 0603) 412-MC2-1551 2
R540,541 nsp CHIP RESISTOR(4.7K OHM,1/10W,0.5%,TP 0603) 412-MC2-1547 2
R542,543 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,D,TP) 412-500C-1558 2
R544,545 nsp CHIP RESISTOR(7.5KOHM,D,TP 0603) 412-6K2-1662 2
R546,547 nsp CHIP RESISTOR(1KOHM,D,TP 0603) 412-6K2-1661 2
R548 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R549,550 nsp CHIP RESISTOR(10OHM,D,TP 0603) 412-6K2-1659 2
R551 nsp CHIP RESISTOR(4.7K OHM,1/10W,0.5%,TP 0603) 412-MC2-1547 1
R552,553 nsp CHIP RESISTOR(47K OHM,1/10W,D,TP 0603,50V) 412-500C-1557 2
R554 941129500870P CHIP RESISTOR(24K OHM,1/10W,0.5%,TP 0603) 412-MC2-1549 1
R555 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,D,TP) 412-500C-1558 1
