Denon MC6000MK2EM - Part Reference List

Exploded
14
Exploded
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
5 941639101240P CONRTOL 1 PCB ASS'Y 704-6K2-A615 1 *
6 941639101250P CONRTOL 2 PCB ASS'Y 704-6K2-A616 1 *
7 941639101260P MAIN PCB ASS'Y 704-6K2-A617 1 *
8 941639101270P IO PCB ASS'Y 704-6K2-A618 1 *
9 941639101280P FRONT PCB ASS'Y 704-6K2-A619 1 *
10 941412101220P CROSS FADER PCB ASS'Y 704-6K2-A685 1 *
10-2 - CROSS FADER PCB(BARE) 405-MC6000-2785 1 -
3 941412101200P WHEEL ASS'Y 701-6K2-5383 2 *
3-1 nsp WHEEL & SHAFT ASS'Y 701-2000-5160 1 -
3-2 nsp WHEEL PLATE 501-6K2-2588 1 -
3-3 nsp SCWER(SAE1018,STS,2.0*3mm) 602-STS2003-677 1 -
3-4 nsp
TOUCH SCRATCH SPRING(SUS304,∮0.3,L=6)
603-M1-384 1 -
4 941403100930P TOP PANEL 703-6K2-1398 1 *
4-1 - GUARD PLATE 300-RCIE-1903 1 -
4-2 - FRONT PANEL(SECC,1.0t) 300-6K2-2113 1 -
11 00D9410057301 POWER KNOB(ABS,PS200-10%) 100-HDJ2000-1641 1
12 90M09CW259020 KNOB PROTECTOR 100-HDJ2000-1642 1
13 941412005080P PUSH KNOB(MIDDLE) 100-UDJ3EB-2213 2
14 00D9587012907 ROTATY KNOB(PP+TPR) 100-300-2226 2
15 00D9587045709 JOG TUNING KNOB 100-900-2298 1
16 00D9587045709 ROTARY KNOB(PP WHITE,TPR GRAY) 100-6000-2298 5
17 412510031005P ROTARY KNOB(ABS PA-757WHITE,8211-45W237B 100-1100-2633 1
18 412510032008P ROTARY KNOB(ABS PA-757WHITE,8211-45W237B 100-1100-2634 18
19 941412005100P ROTARY KNOB 100-6000-2634 3
21 nsp CORD BUSH(NYLON66/101F) 100-K1-2682 1
22 941412100970P ENCODER KNOB 100-1000S-2736V 3
23 nsp JACKET RING 100-2000-2774 1
24 941412005110P ROTARY KNOB(ABS,BLACK) 100-6000-2796 5
25 941404100620P SIDE COVER 100-6K2-2798 2 *
26 941412101160P FADER KNOB 100-22-2824 5 *
27 nsp LED LENS 100-3000-2865 2 -
28 941412101150P
VOL. KNOB 100-6K2-3080 8 *
29 00D9587013605 GROUND PIN 200-DJ100-231 1
30 nsp GROUND PLATE 300-3000-1953 4
31 nsp BOTTOM BASE 300-6K2-2114 1
32 941606502370P 24P FFC CABLE 406-6K2-1284 1 *
33 941606502380P 14P 1.0 FFC CABLE (L=57mm) 406-6K2-1268 1 *
34 941606502390P 10P 1.0 FFC CABLE (L=370mm) 406-6K2-1269 1 *
35 941606502400P 20P 1.0 FFC CABLE (L=70mm) 406-6K2-1270 1 *
36 nsp 1P GROUNG WIRE 406-6K2-1272 2
37 941606502410P 32P 1.0 FFC CABLE (L=60mm) 406-6K2-1273 1 *
42 nsp TWIN ADHESIVE 508-2000-110 1
44 nsp PULLEY SPRING 603-PROS2-256A 2
45 941411103010P BUTTON (FX1) 604-6K2-626 1 *
46 941411103020P BUTTON (FX2) 604-6K2-627 1 *
47 941411103000P BUTTON (MIXER) 604-6K2-628 1 *
48 941411102960P BUTTON (MIC) 604-6K2-629 1 *
49 941411102970P BUTTON (PLAY-CUE) 604-6K2-630 2 *
50 941411102980P BUTTON (CUE1) 604-6K2-631 1 *
51 941411102990P BUTTON (CUE2) 604-6K2-632 1 *
52 941411103030P BUTTON (KEY-LOCK) 604-6K2-633 2 *
53 nsp PULLEY WASHER 606-F200-003 2
54 nsp E RING 606-DJ3000-105 2
55 nsp
WASHER(∮8*3.2*1t,NI)
606-Q2221-122 1
56 nsp FOOT 612-HV3500K-055 4
57 nsp HIMILON(t=0.5) 612-900-219 10
60 00D9410006006 SCREW(SAE1018PTP3*8) 602-B600-057 3
61 nsp SCREW(2.6*8 TTP) 602-SL24F-099 35
62 nsp
SCREW(BTF,∮2.6,L=8,C-1018)
602-HP1010K-182 20
63 nsp SCREW(ISOF,3*4,ZS,Cd,Pb,Hg) 602-SA12-414 2
64 nsp SCREW(TTS,3*8,ZB) 602-DCM280-429 3
65 nsp SCREW(TTB,2*5,MC) 602-A700-494 4
68 nsp
SCREW(WISO,M3*6,∮4.9,WISO,C-1018)
602-WISO3006-652B
1
66 nsp SCREW(M2*L3) 602-MK9-505 12
67 nsp SCREW(SAE1018,PTF,3*10) 602-PTF3010-585 2
69 nsp SCREW(C-1018,2*5mm,M) 602-ISOF2005-686B 1
70 nsp SCREW(ISOK,3*8,C-1018) 602-ISOK3008-705B 12
71 nsp SCREW(BTB,3*8,C-1018) 602-BTB3008-706B 22
72 nsp
SCREW(∮2.6,L=8)
602-BTB2608-708B 16
73 nsp WINDING FIXTURE(SPTE t=0.3 WC-1A) 300-HM510B-224 3
74 nsp CH FIXED PLATE 300-6K2-2115 2
75 nsp ISOLATION 501-6K2-2600 1
76 nsp ISOLATION 501-6K2-2606 1
77 nsp CABLE TIE 504-S100-004 3
78 nsp CANOE CLIPS(MB-1S) 504-HF6011-5011 2
79 nsp CS FIXED PLATE(SECC,1.0t) 300-6K2-2116 1
80 nsp 1P GROUNG WIRE 406-6K2-1271 1
81 nsp SCREW(3*5 P=0.5) 602-B300-041 2
82 nsp CUSHION 612-R1-454 2 *
83 941441100830P CHASSIS ASS'Y (INCLUDE) 701-6K2-5419 1 *
2 nsp CHASSIS 701-6K2-5347 1
20 - LED LENS 100-700-2680 4
43 -
NUT(M3*∮6,C-1010)
601-4500-004 5
58 - VR CUSHION(T=0.3mm,45mm) 612-IM-296 4
59 - HIMILON 612-6K2-492 2
