DISASSEMBLY
Disassemble in order of the arrow of the figure of following flow.
In the case of the re-assembling, assemble it in order of the reverse of the following flow.
In the case of the re-assembling, observe "attention of assembling" it.
TOP COVER
SIDE COVER (L) SIDE COVER (R) P.AMP(R) UNIT
Refer to "DISASSEMBLY 3.P.AMP(R) UNIT"
and "EXPLODED VIEW"
P.AMP(L) UNIT INPUT UNIT and PH/CD TER.UNIT
P.AMP(R) UNIT
Refer to "DISASSEMBLY 1.P.AMP(R) UNIT" Refer to "DISASSEMBLY 2.INPUT UNIT (Ref. No. of EXPLODED VIEW : 3-2)
and "EXPLODED VIEW" and PH/CD TER.UNIT" and "EXPLODED VIEW" MULTIPLIER UNIT
P.AMP(L) UNIT INPUT UNIT (Ref. No. of EXPLODED VIEW : 3-4)
(Ref. No. of EXPLODED VIEW : 3-1) (Ref. No. of EXPLODED VIEW : 1-1)
MULTIPLIER UNIT PH/CD TER.UNIT
(Ref. No. of EXPLODED VIEW : 3-3) (Ref. No. of EXPLODED VIEW : 3-7)
CONECT UNIT
Refer to "EXPLODED VIEW"
CONECT UNIT
FRONT PANEL ASSY BOTTOM COVER
(Ref. No. of EXPLODED VIEW : 1-8)
Refer to "DISASSEMBLY 4.FRONT PANEL ASSY" Refer to "DISASSEMBLY 5.BOTTOM COVER"
and "EXPLODED VIEW" and "EXPLODED VIEW"
DIRECT SW UNIT DIODE UNIT
AC UNIT
(Ref. No. of EXPLODED VIEW : 1-2) (Ref. No. of EXPLODED VIEW : 1-7) Refer to "EXPLODED VIEW"
MAIN VR UNIT CONTROL UNIT AC UNIT
(Ref. No. of EXPLODED VIEW : 1-3) (Ref. No. of EXPLODED VIEW : 2) (Ref. No. of EXPLODED VIEW : 1-9)
F SW UNIT
(Ref. No. of EXPLODED VIEW : 1-4)
CE33W==123M
REC OUT SEL. SW UNIT Refer to "DISASSEMBLY 8.CE33W==123M"
REC OUT UNIT
(Ref. No. of EXPLODED VIEW : 1-5) and "EXPLODED VIEW" Refer to "EXPLODED VIEW"
P DIRECT SW UNIT REC OUT UNIT
(Ref. No. of EXPLODED VIEW : 1-6) (Ref. No. of EXPLODED VIEW : 3-8)
P SWITCH UNIT
(Ref. No. of EXPLODED VIEW : 1-10)
P LED UNIT
SP TERMINAL UNIT
(Ref. No. of EXPLODED VIEW : 1-11) Refer to "EXPLODED VIEW"
TONE UNIT SP TERMINAL UNIT (L-ch)
(Ref. No. of EXPLODED VIEW : 3-5) (Ref. No. of EXPLODED VIEW : 95-1)
H/P UNIT SP TERMINAL UNIT (R-ch)
(Ref. No. of EXPLODED VIEW : 3-6) (Ref. No. of EXPLODED VIEW : 95-2)
FLAT AMP UNIT and POWER SUPPLY UNIT
Refer to "EXPLODED VIEW"
FLAT AMP UNIT
(Ref. No. of EXPLODED VIEW : 4-1)
POWER SUPPLY UNIT
(Ref. No. of EXPLODED VIEW : 4-2)
