Denon PMA-A110 User Manual

Connecting a pre-amplifier
.
AUDIO
OUT
LR
R
R
L
L
Pre-amplifier
0
The EXT.PRE input terminals are equipped with a short pin-plug. Remove this plug to connect a pre-amplifier. Store the removed short pin-plug in a safe place so as not to
lose it.
Contents Connections Playback Settings Tips Appendix
21
Front panel Rear panel
Remote control
unit
Index

Denon PMA-A110 Specifications

General

Input Sensitivity MM	2.5 mV / 47 kOhm
Treble Control	±8 dB at 10 kHz
Bass Control	±8 dB at 100 Hz
Standby Consumption	0.2 W
Dimensions	434 x 182 x 450 mm
Total Harmonic Distortion	0.007%
Frequency Response	5 Hz - 100 kHz
Input Sensitivity MC	200 µV / 100 ohm
Power Output (8 Ohm)	80 W (20 Hz - 20 kHz, THD 0.07%)
