Denon PMA-A110 User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
.
2
Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3
Put the rear lid back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 7 m
30°
Contents
Connections Playback Settings Tips Appendix
5
Front panel Rear panel
Remote control
unit
Index

Denon PMA-A110 Specifications

General

Input Sensitivity MM	2.5 mV / 47 kOhm
Treble Control	±8 dB at 10 kHz
Bass Control	±8 dB at 100 Hz
Standby Consumption	0.2 W
Dimensions	434 x 182 x 450 mm
Total Harmonic Distortion	0.007%
Frequency Response	5 Hz - 100 kHz
Input Sensitivity MC	200 µV / 100 ohm
Power Output (8 Ohm)	80 W (20 Hz - 20 kHz, THD 0.07%)
