Specifications
o
Power amplifier section
Rated Output Power: 2-channel driving (CD → SP OUT)
80 W + 80 W (8 Ω/ohms, 20 Hz - 20 kHz, T.H.D. 0.07 %)
160 W + 160 W (4 Ω/ohms, 1 kHz, T.H.D. 0.7 %)
Total harmonic distortion: 0.01 % (Rated output: –3 dB), 8 Ω/ohms, 1 kHz
Output terminals: Speaker: 4 – 16 Ω/ohms
Suited for headphones/stereo headphones
Input Sensitivity/Input Impedance: EXT.PRE: 0.9 V / 47 kΩ/kohms
Amplification factor: 29 dB
o
Pre amplifier section
Input Sensitivity/Input Impedance: PHONO (MM): 2.5 mV / 47 kΩ/kohms
PHONO (MC): 200 μV / 100 Ω/ohms
CD, NETWORK/AUX, RECORDER: 135 mV / 19 kΩ/kohms
RIAA Deviation: PHONO: 20 Hz – 20 kHz ±0.5 dB
Maximum Input: PHONO (MM): 130 mV / 1 kHz
PHONO (MC): 10 mV / 1 kHz
