q Power operation button (X) ··············································· (8, 16)
w Power indicator ········································································· (8)
e USB port ····················································································· (5)
r Disc tray ··················································································· (30)
t Headphones jack (PHONES)
When the headphones are plugged into this jack, audio will no
longer be output from the connected speakers.
NOTE
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
y SOURCE button ································································· (10, 23)
u VOLUME control knob ···························································· (10)
i Reverse-skip/Forward-skip buttons
Preset/Tuning buttons
(8/–, +/9) ················································ (11, 14, 17, 20, 23)
o Stop button (2) ··························································· (11, 13, 20)
Q0 Play/Pause button (1/3) ································· (8, 11, 17, 19, 20)
Q1 Disc tray open/close button (5) ··············································· (8)
Q2 Remote control sensor ··························································· (29)
Q3 Display
Front panel
For buttons not explained here, see the page indicated in parentheses ( ).
q w e r t y u
o
i
Q1
Q2
Q3
Q0
Image when viewed
from the top of the front
panel
Part names and functions
