GASOLINE LAWN MOWER
EN
Model GLD-520SP-BS (588077)
5
12
8
14
11
13
1
6
7
2
10
3
9
4
1. Blade drive lever
2. Wheel drive lever
3. Oil ller complete with dipstick
4. Mow height adjustment lever
5. Grass catcher
6. Fuel tank lid
7. Starter handle
8. Air lter
9. Silencer
10. Spark plug
11. Grass catcher ll indicator
12. Side discharge deector
13. Throttle control
14. Starter handle holder
Fig. 1d
PRELIMINARIES
Unpacking
The buyer purchases the lawn mower as packed in a carton transport box which can include special protective
elements inside to ensure additional protection of the cargo during transportation.
To extract the device from the package, remove the transport tape, open the box, and carefully take out all
the components.
IMPORTANT!
After unpacking and transportation, make sure to check the delivery set for completeness,
and the lawn mower for operability.
We recommend you retain the packaging materials for the case of future transportation.
Assembling
IMPORTANT!
In avoidance of inadvertent damage, do not exert excessive eorts while assembling
the device.
