Depstech DS590 - User Interface Introduction; Preview Screen Elements; Photo and Video Capture

- 03 -
TF Card Slot
10
11
• Short click the reset button with the reset pin,
the device will be shut down and reseted.
Reset Button
12
• Red LED indicator flashes: Charging
• Red LED indicator stays on: Charging finished
Charging Status LED Indicator
9
• Support up to 32G TF card
• Please format it on first use
UI Introduction
Photo Shoot/Video Record
TF Card Status
Screen Rotation 180°
Battery Power
Main Lens
Side Lens(B)
Side Lens(C)
Timestamp
Preview
Tips:
Dual Lens: A:Main Lens B:Side Lens
Triple Lens: A:Main Lens B:Side Lens(B) C:Side Lens(C)
Type-C Charging Port
• For charging (Type-C cable connected to the adapter)
• For data transmission (Type-C cable connected to PC client)
