Depstech DS590 - Product Introduction and Controls; Device Control Button Functions

- 02 -
Product Introduction
2
• Click to rotate the real-time image 180°
• Hold this button for 2s to switch main/side camera
(Only applicable to dual-lens products)
3
• Click to enter the menu
4
• Single press to take a photo or end the video record
• Hold this button for 2s to start a video record
1
• Hold this button for 2s to power on/off the endoscope
6
• Click to increase the LED lights brightness of the camera
• Move the cursor down(When in the menu)
7
• Hold this button for 2s to enter/exit the album
• Click to confirm the selections (When in the menu)
5
• Click to dim the LED lights of the camera
• Move the cursor up(In the menu)
8
• Air plug interface
1
4
7
6
3
2
8
5
