19.4.3 Red 633nm Treatment
* Navigation: Home - Red Treatment
Button/ ID Function
Requirement
3
Press the RED button to activate the red LED’s.
This is indicated by the button illuminating in red.
5
In the RED TREATMENT screen, if the PLAY button is
pressed the treatment is in progress or Paused.
Figure 9: Controller Overview for Red Treatment.
19.4.4 Blue 415nm Treatment
Button/ ID Function
Requirement
2
Press the BLUE button to activate the blue LED’s.
This is indicated by the button illuminating in blue.
5
In the BLUE TREATMENT screen, if the PLAY button is
pressed the treatment is in progress or paused.
* Navigation: Home - Blue Treatment
Figure 10: Controller Overview for Blue Treatment.
