Dermalux FlexMD - NIR 830 nm Treatment; Blue & Red Treatment

Aesthetic Technology Limited
30 31
PL-027 (Rev 7) PL-027 (Rev 7)
19.4.5 NIR 830nm Treatment
* Navigation: Home - NIR Treatment
Button/ ID Function
Requirement
4
Press the NIR button to activate near infra-red LED’s.
This is indicated by the button illuminating in yellow.
5
In the NIR TREATMENT screen, if the PLAY button is
pressed the treatment is in progress or paused.
Figure 11: Controller Overview for NIR Treatment.
19.4.6 Blue & Red Treatment
Button/ ID Function
Requirement
2
Press the BLUE button to activate the blue LED’s.
This is indicated by the button illuminating in blue.
3
Press the RED button to activate red LED’s.
This is indicated by the button illuminating in red.
* Navigation: Home - Blue & Red Treatment
5
In the BLUE & RED TREATMENT screen, if the PLAY button
is pressed the treatment is in progress or paused.
Figure 12: Controller Overview for Blue & Red Treatment
