Immunity test IEC 60601 test level Compliance level
Electromagnetic
Environment –
Guidance
Interference
voltages / Surges
pursuant to
IEC 61000-4-5
±1kV voltage
differential mode
±2kV common
mode
±1kV voltage
differential mode
±2kV common
mode
Main supply voltage
should be of the same
quality as in a typical
commercial, living or
hospital environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
pursuant to
IEC 61000-4-11
<5% U
T
(>95% dip
of U
T
) for ½ period
40% U
T
(60% dip
of U
T
) for 5 periods
70% U
T
(30% dip
of U
T
) for 25 periods
<5% U
T
(>95% dip
of U
T
) for 5s
<5% U
T
(>95% dip
of U
T
) for ½ period
40% U
T
(60% dip
of U
T
) for 5 periods
70% U
T
(30% dip
of U
T
) for 25 periods
<5% U
T
(>95% dip
of U
T
) for 5s
Main supply voltage
should be of the same
quality as in a typical
commercial, living or
hospital environment.
If the user of the PRO-
II
®
or PRO-III
®
device
requires continued
operation during
mains power outages,
it is recommended to
power the device from
an uninterruptible
power supply or a
battery.
Magnetic fields at
power frequency
(50/60 Hz)
pursuant to
IEC 61000-4-8
3 A/m 3 A/m
Power frequency
magnetic fields should
be at levels
characteristic for a
typical location in a
typical commercial,
living or hospital
environment.
Note: U
T
is the AC mains voltage prior to the application of the test levels.
41
Table 3
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The PRO-II
®
and PRO-III
®
devices are intended for operation in the electromagnetic
environment specified below.
The customer or user of the PRO-II
®
or PRO-III
®
device must ensure that it is used in
such an environment.
Immunity tests
IEC 60601 test
level
Compliance level
Electromagnetic
Environment – Guidance
Conducted RF
disturbances
pursuant to
IEC 61000-4-6
Radiated RF
disturbances
pursuant to
IEC 61000-4-3
3 V
eff
150 kHz to
80 MHz
3 V/m
80 MHz to
2.5 GHz
3 V
eff
3 V/m
Portable and mobile RF
communications equipment
should be used no closer to
any part of the PRO-II
®
and
PRO-III
®
devices, incl.
cables, than the
recommended separation
distance calculated from
the equation applicable to
the frequency of the
transmitter.
Recommended separation
distance:
d= 1.2 √P
d= 1.2 √P for 80 MHz to
800 MHz
d= 2.3 √P for 800 MHz to
2.5 GHz
Where P is the maximum
output power rating of the
transmitter in watts (W)
according to the
transmitter manufacturer
and d is the recommended
separation distance in
meters (m).
Field strength from fixed
RF transmitters, as
determined by an
electromagnetic site
survey
a
, should be lower
than the compliance level
in each frequency range.
b
Interference is possible in
the vicinity of devices
bearing the symbol shown
below.
