Appendix e
OTHER APPROVALS
The following items, functions and options describe various other approvals applicable to the Model PIRECL.
SIL APPROVAL
IEC 61508
Certified SIL 2 Capable.
For specific information regarding SIL models, refer to the Safety Reference Manual, form 95-8630.
DNV
Type Approval Certificate No. A-11023.
Subject Matter of the Approval
ModelPIRECLIRHydrocarbonGasDetectorandPIRTBTerminationBoxarefoundtocomplywithDetNorskeVeritas’
RulesforClassicationofShipsandDetNorskeVeritas’OffshoreStandards.
Application/Limitation
Location Classes
MODEL TEMPERATURE HUMIDITY VIBRATION EMC ENCLOSURE
PIRECL D B B B C
Relevant tests according to “Standard for Certification No. 2.4”.
MED
Certificate No. MED-B-5866.
Model PIRECL IR Hydrocarbon Gas Detector and PIRTB Termination Box are found to comply with the requirements
in the following Regulations/Standards:
Annex A.1, item No. A.1/3.54 and Annex B, Module B in the Directive. SOLAS 74 as amended, Regulation II-2/4 &
V1/3 and FSS Code 15.
The equipment is found to comply with the following location/application dependent requirements (for definition of
each of the location classes, see the table below):
MODEL TEMPERATURE VIBRATION EMC ENCLOSURE
PIRECL TEM-D VIB-B EMC-B ENC-C
Definition of the location classes with reference to relevant standards:
Temperature
TEM-D Location (–25°C to +70°C) (ref. IEC 60092-504 (2001) table 1 item 6-7)
Vibration
VIB-D For eq. on reciprocating machines etc. (ref. IEC 60092-504 (2001) table 1 item 10)
EMC
  EMC-BBridgeandopendeckzone(ref. IEC 60092-504 (2001) table 1 item 19-20)
Enclosure
  ENC-COpendeck(IP56)(ref. IEC 60092-201 table 5).
