8525-0374-0M Rev A y Physician’s Scale Owner’s Manual
7
WHEEL ASSEMBLY INSTALLATION
IMPORTANT! Mounting the wheel assembly upside down on the scale base will
cause weighing errors.
1. Align the mounting bracket of the wheel assembly to the scale base as shown in Figure 8.
2. Using the screws and washers that are included, attach the wheel assembly to the scale
base. Adjust the wheel assembly to a level position, and then tighten the screws.
3. When moving the scale, hold the column and tip the scale backward to keep the front of
the scale base away from the floor.
Figure 8. - Attaching wheel assembly to scale base
Bottom
Top
