8525-0374-0M Rev A y Physician’s Scale Owner’s Manual
6
HEIGHT ROD INSTALLATION
1. Place the slotted holes of both brackets on the back of the height rod over the two screws
on the front of the column as shown in Figure 7 and pull down.
2. Use the enclosed wrench to tighten the two hex-head screws. Be sure not to over-tighten.
3. To raise or lower the height rod, press the red button at the top of the height rod.
Figure 7. - Place slotted holes in height rod brackets over screws in column
Slotted Holes
Red Button
