2 Specifications
Table 1 – Outdoor Unit Specifications
Model COND-OCD-09 COND-OCD-12 COND-OCD-18 COND-OCD-24 COND-OCD-30 COND-OCD-36
Power Supply 208/230 VAC, 60 Hz, 1 phase
Cooling Capacity (min-max) BTU/h 9000 (3100-9600) 12000 (3100-13000)18000 (6800-20000) 22000 (6824-27296) 28000 (9490-30030) 33600 (7400-36000)
Heating Capacity (min-max) BTU/h 11000 (1911-12000) 13000 (2400-14000) 19800 (7340-23500) 23000 (6824-30708) 28400 (10000-32990) 34600 (14980-36000)
Cooling Input (min-max) W 630 (160-1300) 960 (200-1350) 1435 (450-2150) 1830 (450-3000) 2750 4100
Heating Input (min-max) W 1020 (160-1350) 1100 (400-1400) 1730 (580-2600) 2000 (450-3000) 2800 3800
Rated Input W 1350 1400 2600 3000 4000 4300
Rated Current A 6.0 6.3 12.5 14.5 17.5 20
MCA A 9 9 16 20 20 24
MOCP A 15 15 25 30 30 40
EER BTU/h/W 14.0 12.5 12.5 12.5 10.3 8.2
COP W/W 3.16 3.46 3.35 3.37 3.00 2.70
SEER 23 22 20 20 18 18
HSPF 10.5 10.1 10.0 10.0 9.0 9.0
Compressor Type Swing Swing Rotary Rotary Rotary Rotary
Compressor LRA A - - 25 25 40 67
Compressor RLA A 4.00 4.00 12.08 11.50 13.50 13.50
Compressor Power Input W 845 845 1440 2550 2450 3010
Fan Motor RLA A - 0.36 0.49 0.65 0.45 0.89
Fan Motor Power W 30 30 60 92 120 170
Air Flow Volume CFM 1059 1177 3200 4000 2354 2589
Throttling Method Electronic expansion valve
Cooling Amb. Temp. °F 0 - 115
Heating Amb. Temp. °F -4 - 75
Sound Pressure Level dB(A) 53 54 55 59 62 65
Unit Dimension (W x H x D) in 33.4 x 21.3 x 12.6 33.4 x 23.3 x 12.6 37.6 x 27.6 x 15.6 38.6 x 31.1 x 16.8 39.5 x 31.1 x 14.6 39.5 x 31.1 x 14.6
Net Weight lb 78 86 106 142 154 161
Refrigerant R410A
Refrigerant Charge oz 45.9 47.6 56.44 81.1 84.66 91.71
Additional Charge oz/ft 0.2 0.2 0.2 0.5 0.5 0.2
Pipe Length ft 24.6 24.6 24.6 24.6 24.6 24.6
Pipe Max Length ft 49 66 82 82 98 98
Pipe Max Height ft 33 33 33 33 33 33
Pipe Diameter See cover page
