Dettson HYDRAT15-E2401M - Figure 2: Menu Navigation

Figure 2 – Menu Navigation
PUMP : OFF
SET P : 149.0°F
TARGET : 149.0°F
T° IN : 62.5°F
T° OUT : UNUSED
Cmd : 0%
INSTALLER
CONFIGURATION
ALARM
BOOST MODE
STATUS:
INACTIVE
o to switch
DUAL ENERGY
AUTO
o to switch
INSTALLER
PASSWORD
****
INSTALLER
-> TYPE : MAN.
PUMP : OFF
SET P : 149 °F
T° OUT : UNUSED
↓
INSTALLER
↑
-> ENERGY : ELEC
OFFSET : NO
TESTS
BACK
CONFIGURATION
HYDRA III 20kW
-> UNITS °F
LANGUAGE EN
POWER HIGH
BACK
ALARM
-> CURRENT
PAST
CLR. ALARM
BACK
CONSUMPTION
APPROX: 13.2kWh
12 hours ago
press o to reset
* This menu will only
display if the energy
option is set to ‘DUAL’
in the installer menu
11
