Dettson HYDRAT15-E2401M - Table 5: Parts List; Table 6: List of Wires

Table 5 – Parts List
# Item Description Note
1 B04493 Cover assembly 15-20 kW Cover, cosmetic and wiring diagram
2 B04494 Cover assembly 24-29 kW Cover, cosmetic and wiring diagram
3 R02L007 Manometer
4 L01J001 Breaker 15A
5 G08F005 Reducer 1 x 3/4 Black 15-20 kW
6 G08F010 Reducer 1 1/4 x 3/4 Black 24-29 kW
7 G11Z002 Drain faucet 3/4m
8 B04481 Jacket 15-20 kW Painted steel
9 B04495 Jacket 24-29 kW Painted steel
10 B04201 Machine bracket
11 B03952 Wall bracket
12 B04485 End plate 15-20 kW
13 B04500 End plate 24-29 kW
14 R02Z010 Temperature sensor
15 B04237-02 Kit element 4 kW Element and gasket
16 B04237-03 Kit element 5 kW Element and gasket
17 B03970 Sealing gasket
18 G11F025 Relief valve 30# 3/4m x 3/4f
19 B04505 Aquastat
20 B04487-01 Thermodisc support assembly
21 K03082 Relay control board Replacement kit
22 B04474 Control support
23 L01G011 Fuse 2A
24 K03083 Dettson control Replacement kit
25 L01F010 Transformer 208/240V - 24V
26 A20015 Exterior sensor -12 C
27 L99F007 Terminal block
28 L01H009 Control relay 24VAC
29 L01H030 Relay DPST 22VDC
30 R99G006 Rectifier control
Table 6 – List of Wires
Item Description Note
A00223-14 Wire terminal P black
A00400-06 Wire transformer red
A00400-07 Wire breaker black
A00411-01 Wires neutral (N) white
A00415-08 Single wire terminal-relay red 15, 24 kW
A00415-09 Single wire terminal-relay black 15, 24 kW
A00420B Wiring 120V black
A00421B Wire exrterior probe
A00423-01 Flat wire
A00435-03 Double wire terminal-relay black
A00435-04 Double wire 14" red 18-29 kW
A00435-05 Double wire 6" red
A20009-06B Wire element black
A20009-07B Wire element red
A20024-06 Wire relay-relay red 15-20 kW
A20024-11 Wire relay-relay red 24-29 kW
B04476 24V wiring 15-20 kW
B04479 24V wiring 24-29 kW
