6 TECHNICAL DATA
Table 4 – Technical Specifications
Model number
Power (kW @240V / @208V)
Electric element #1 (kW) Electric element #2 (kW) Electric element #3 (kW) Electric element #4 (kW) Electric element #5 (kW) Electric element #6 (kW)
Consumption (A @240V / @208V)
Suggested wire size (Cu / Al)
Suggested breaker size (A @240V)
Voltage - Frequeny - Phase
Supply - Return
Dimensions (L x P x H) in
Shipping weight (lbs)
HYDRAT15-E2401M 15 / 11,3 5 5 5 - - - 63 / 54 6 / 4 80
240/208V - 60Hz - 1
1" NPT Female
8,2 x 12,4 x 21,4
65
HYDRAT18-E2401M 18 / 13,5 4 5 4 5 - - 75 / 65 4 / 2 100
HYDRAT20-E2401M 20 / 15,0 5 5 5 5 - - 83 / 72 3 / 2 110
HYDRAT24-E2401M 24 / 18,0 4 5 5 5 5 - 100 / 87 2 / 0 125
1 1/4" NPT Female
11,2 x 12,4 x 21,4
85
HYDRAT27-E2401M 27 / 20,3 4 4 5 4 5 5 113 / 98 1 / 00 150
HYDRAT29-E2401M 29 / 21,8 4 5 5 5 5 5 121 / 105 1 / 00 175
In all cases, refer to applicable local and national codes
