Deus CT1 24 - Installation; Installation of the Gearmotor Components; Installation and Fixing of the Anchoring Plate

P.5
DX
SX
200
350
250
DX
SX
200
350
250
2
1
ATTENTION:
If the gearmotor is subjected to severe working condi!ons or if the weight of the gate
exceeds 300 kg, the anchoring plate must necessarily be fixed by "drowning" it in the concrete.
Le-hand closing
2 - INSTALLATION
Right-hand closing
2.1 - Installaon of the gearmotor components.
The gearmotor installa!on area must provide the space necessary to carry out maintenance and
manual release opera!ons.
2.2 - Installaon and fixing of the anchoring plate.
a) Respect the dimensions in the image.
b) In order to place the anchor plate correctly, respect its orienta!on (LEFT - RIGHT) as shown in
the image.
c) Respect the height dimensions as indicated in the image with pinion Z16.
d) Posi!on the pipes of the electric cables, leaving them protruding and capping them, to
prevent them from filling up with debris.
A$ach the anchor plate to the concrete base with 2 expansion anchors or submerge in the
fresh concrete the two "L".
