Press UP or DN to move navi g ation mark to ELEV(take RP P e Swito h
Elevator for example), Press R or L to shift the status between
nomal and reverse. These are two status for option. And the
default settin g is Normal. All Channels Reverse Switch like:
Aileron, Throttle, Rudder, Gear, Pitch and Aux2 can be
referred to the way of ELEV Reverse Switch. And press EXT Aileron
to exit after finishin g settin g .
3.2 Travel Adjust
Press ENT to enter into Main Menu. Press UP or DN to move navi g ation mark to select item Function Menu.
Press ENT to enter Function Menu. Press UP or DN to select Travel Ajust, Press ENT to enter Travel Adjust
interface, as below illustration. It shows the Travel Adjust status of one channel:
Travel Adjust
Elevator
Take ELEV for example, Press UP or DN to move navi
g ation
to desired item Elevation of U. Press R or L to increase or
decrease the servo travel ran g e. The adjustment ran g e is
from 0.0% to 150.0%. The factory default is 100.0%.
D uu,
Press UP or DN to move navi g
ation mark to desired item D of ELEV. Press R or L to increase or decrease
the servo travel ran g e. The ran g e is from 0.0% to 150.0%. The factory default is 100.0%.
All other channel's Travel Adjust like Aileron, Throttle, Rudder, Gear, Pitch and Aux2 can be referred to ELEV
travel Ajust. Press EXT to exit after settin g finished.
3.3 Sub Trim
NOTE: Sub Trim is used to fine tune the servo neutral position durin g setup. In order to avoid pushin g the
servo beyond it's limits and possibly causin g dama g e it is advised to first mechanically adjust the servo arm/bell
crank to be as close to the neutral point as possible. Only when this is complete may sub trim be used to
make a final a djustment.
Settin g method:
Press ENT to enter Main Menu, Press UP or DN to move
the navi g ation mark to desired item Function Menu. Press
ENT to enter Function Menu, Press UP or DN to select
Sub trim, and press ENT to enter Sub Trim interface.
The interface show the items and the channels which are adjustable. Press R or L to chan g e the neutral point
of Servos. The default for every channel is 0.0%. The permitted adjustment ran g es are show in the table below:
Adjustment ran g e Channel name Adjustment ran g e
Elevator
D62.5%--U62.5% Gear -62.5%—+62.5%
Aileron R62.5% —L62.5% Pitch L62.5% — H62.5%
Throttle L62.5% —H62.5% AUX2 -62.5% —+62.5%
Rudder R62.5%—L62.5%
Press EXT to exit after adjustment finished.
3.4 Dual rate and Exponential
Dual Rate/Exponential is a function which permits a chan g e in behavior of the control sticks between pre-
defined settin g s. Dual Rate alters the maximum and minimum servo travel available, Expo has no effect on
the maximum or minimum travel but decreases or increases the sensitivity to stick movement in an exponential
manner. One use of Dual Rate/Expo is to reduce the sensitivity of the controls when landin g .
Elevator
Sub Trim
Elev;=1.to:
Aileron
