3. Mount and reassemble the thermostat.
▪
Fasten the thermostat to a socket or an exterior
wall box by driving the screws through the holes
in each side of the thermostat.
▪
Install the frame and front cover in the reverse or-
der of disassembly.
4. Turn on the power supply.
3 Settings
How to change the minimum and maximum floor tem-
peratures
1. Remove the adjustment
button.
2. Move the pins to the de-
sired positions.
3. Put the adjustment but-
ton back in place.
Note: Please be aware of the following:
▪
The floor temperature is measured where the floor
sensor is placed.
▪
The temperature of the bottom of a wooden floor can
be up to 10 degrees higher than the top.
DEVIreg™ 530
10 Installation Guide
