DeVilbiss Compact Series - Parts List

© 2003 ITW Finishing Systems and Products
4
Parts List
Ref. No Description Part Number Qty Options
1 Air Cap/Retaining ring
COM-522 or COM-510
SP-100-***-K 1 522, 510, 505,523
e.g *** = 522
+ 2 Nozzle SP-200S-**-K 1 085,10,11,12,13,14,
16,18,20,22
e.g ** =14 =1.4 mm
+ 3 Separator SP-623-K5 5
+ 4 Packing GTI-445-K2 2
5 Spreader Valve SP-401-K 1
6 Stud and Screw GTI-408-K5 5
7 Needle Adjusting Screw SP-614-K 1
+ 8 Spring SP-622-K5 1
9
Needle SP-300S-**-K 1 085,10,11,12,13,14,
16,18,20,22
e.g ** =14 =1.4 mm
Needle—Plastic tipped SP-300P-**-K 10, 12, 14
e.g ** =14 =1.4mm
10 Airvalve housing + seal SP-612-K 1
+ 11 Spindle 1
12 Trigger SP-617-K 1
13 Connector SP-611-K 1
14 Airflow Valve SP-402-K 1
15 Fluid Inlet Connector and
seal
SP-610–K 1
+ 16 Air Valve Service Kit SPK-101-K 1
17 Retaining Ring and Seals SPK-102-K 1
+ 18 Spreader/ Cheater
Service Kit
Gti-428-K5 5
19 Circlip 25746-007-K5 5
+ 20 Air valve assembly Tool - 1
21 Spanner SPN-5 1
Spraygun Service Kit
(parts included marked + )
SPK-401-** 1 085,10,11,12,13,14,
16,18,20,22
e.g ** =14 =1.4 mm
+
