DeVilbiss FLG-G5 - Parts List

4 © 2012 Finishing Brands UK Ltd.
Parts List
Ref. No
Part Number
Description
Qty
1
SGK-0023
Retaining ring
1
2
FLG-0001-5
Air cap
1
3
SGK-0012-14
SGK-0014-18
SGK-0012-20
Fluid tip 1.4mm
Fluid tip 1.8mm
Fluid tip 2.0mm (available separately)
1
● 4
-
Gasket
1
● 5
-
Baffle
1
 6
-
Packing
1
7
-
Packing gland nut
1
8
-
Retaining ring
1
9
-
Spray pattern adjustment valve bushing
1
10
-
Spray pattern valve
1
11
-
U-cup seal
2
12
-
Air-valve seat
1
13
-
Air-valve stem
1
14
-
Air-valve spring
1
15
-
Air-valve bushing
1
16
SGK-0414
SGK-0418
SGK-0420
Fluid needle 1.4mm
Fluid needle 1.8mm
Fluid needle 2.0mm (available separately)
1

17
-
Fluid needle spring
1
18
-
Fluid adjustment knob
1
19
-
Nipple
1
20
-
Retaining ring
1
21
-
Air adjusting valve head
1
22
-
Air adjusting valve assembly
1
23
-
Retaining ring
1
24
-
Trigger pin assembly
1
25
-
Trigger
1
26
-
Fluid nipple
1
28
KGP-5-K5
Filter
1
29
GFC-402
Lid assembly
1
30
GFC-2-K5
Drip free vent lid kit of 5
1
31
GFC-501
Cup assembly
1
 32
-
Assembly tool
1

K-5040:
Seal, baffle and gasket replacement kit, items 4, 5, 6, 11, 12, 13, 14, and 32
●
K-5030:
Baffle replacement kit, items 4 and 5.
