DeVilbiss GTIPRO LITE - Construction Features; Materials of Construction; Specifications & Technical Data

4 © 2012 ITW Finishing Systems and Products
Kit contents (all models)
1
GTIPRO LITE Suction or Pressure Feed Spray gun
1
Spanner (10mm and 14mm A/F)
1
KR 1 litre Suction feed Cup (Suction models only)
1
Torx / Flat blade screwdriver
1
Cup Filter (Suction models only)
1
Cleaning Brush
1
Set of 4 coloured identification rings
1
Service bulletin
Construction Features
1
Air Cap (nickel plated brass for long durability)
10
Fan Air Adjustment (step-less regulation for fan
to round spray)
2
Air Cap Retaining Ring (allows easy rotation of air
cap)
11
Fluid Adjustment (step-less regulation of fluid
volume)
3
Fluid Nozzle (ideal for most paint systems)
12
Interchangeable Colour ID System (4 coloured
rings supplied)
4
Fluid Needle (grooved stem for easy removal)
13
Anodised, forged aluminium gun body
(ergonomic, good looking & durable, easy to
clean)
5
Fluid Inlet (Universal 3/8” (BSP & NPS) thread –
accepts DeVilbiss and most other cup systems)
14
1 litre Aluminium Suction Cup (Suction models
only)
6
Air Inlet (Universal 1/4 “ thread, accepts BSP & NPS)
15
Cup Lid with Drip Free Vent (avoid drips)
7
Self -Adjusting Needle Packing (for trouble free
operation)
16
Air Valve (design offers low pull force & low
pressure drop)
8
Trigger (ergonomic for comfort)
17
Gun acceptable for waterborne and solvent
borne applications
9
Trigger Stud & Screw (easy replacement design)
Materials of Construction
Gun Body
Anodised aluminium
Air Cap,
Nickel plated brass
Fluid Nozzle, Fluid Needle, Fluid Inlet, Trigger Stud
Stainless steel
Adjusting Knobs
Anodized aluminium
Springs, Clips, Screws
Stainless steel
Seals, Gaskets
Solvent resistant
Trigger
Chrome plated steel
Air Inlet, Body Bushing, Spreader & Cheater Valve Bodies,
Air Valve Nut, Air Cap Retaining Ring, & air valve housing
Chrome plated brass
Air Valve Spindle
Nickel plated brass
Specifications & Technical Data
Air Supply Connection
Universal 1/4" BSP and 1/4" NPS male
Maximum Static Air Inlet Pressure
P1 = 12 bar (175 psi)
Maximum Static Fluid inlet Pressure
P2 = 15 bar (217 psi)
Gun Air Inlet Pressure for HVLP
and High Efficiency
®
both with gun triggered.
1.75 bar (25.4 psi)
2.00 bar (29.0 psi)
Fluid Supply Connection
3/8" BSP
Service Temperature
0 to 40°C (32 to 104°F)
Gun Weight (gun only)
(with cup)
500g
935g
