DeVilbiss GTIPRO LITE - PARTS LIST

6 © 2012 ITW Finishing Systems and Products
PARTS LIST
REF.
NO.
DESCRIPTION
PART NO.
QTY
REF.
NO.
DESCRIPTION
PART NO.
QTY
1
Air Cap Retaining Ring
-
1
33
Air Inlet Kit
SN-9-K
1
2
Slip Ring
-
1
34
Needle Packing
-
1
3
Air Cap
-
1
35
Packing Spring
-
1
4
Air Cap Retaining Clip
JGA-156-K5
1
36
Packing Nut
-
1
5
Retaining Ring Seal
-
1
*37
Packing, Spring and
Packing Nut Kit
SN-404-K
1
6
Aircap & Ring
See chart 1 p13
1
*38
Trigger Screw
-
1
7
Air Cap Retaining Ring
& Seals
PRO-420-K
1
39
Trigger
-
1
8
Fluid Nozzle Kit
See chart 2 p13
1
*40
Trigger Stud
-
1
9
Spray Head
-
1
41
Trigger Stud & Screw
Kit
SP-617-CR-K
1
*10
Spray head Seal
SN-18-1-K2
1
42
Airflow Valve
PRO-407-K
1
11
Spray head kit
SN-69-K
1
43
Circlip - Kit of 5
25746-007-K5
1
*12
Circlip
-
1
44
Valve Head
-
1
13
Valve Body
-
1
45
Washer
-
1
*14
O Ring
-
1
46
Valve Body
-
1
*15
Spreader Valve Pin
-
2
47
Valve Adjusting Knob
-
1
16
Spreader Valve
Adjusting Knob
-
1
48
Seal
SP-636-K
1
17
Spreader Valve
Assembly
PRO-408-K
1
49
Lock nut
-
1
18
Front Valve Seal
-
1
50
Fluid Inlet
-
1
19
Valve Seat
-
1
51
Fluid inlet Kit
ADV-7-K
1
20
Spindle
-
1
Suction Cup Models only
21
Air Valve Spring
-
1
52
Suction Cup Kit
KR-566-1-B
1
22
Rear Valve Seal
-
1
53
Cup Lid Gasket – Kit
of 3
KR-11-K3
1
23
Air Valve Kit
PRO-471
1
54
Drip Check
Diaphragm (kit of 5)
KR-115-K5
1
24
Fluid Needle
See chart 2 p13
1
55
Filter – Kit of 10
KR-484-K10
1
25
Needle Spring
-
1
56
Lid Assembly
KR-4001-B
1
26
Spring Pad
-
1
57
Cup
KR-466-K
1
27
Housing
SN-66-K
1
+58
Air Valve Service Tool
-
1
28
Fluid Adjusting Knob
SN-67-C-K
1
59
Tool Kit
SN-406
1
*29
Needle Spring Kit
PRO-472-K3
1
SERVICE PARTS
30
Gun Body
-
1
Spray Gun repair kit (includes
items marked *)
PRO-470
31
Air Inlet
-
1
Seal and Pin Kit, kit of 5 (items
12, 14 and 15)
GTI-428-K5
32
Colour ID Ring Kit (4
colours)
SN-26-K4
1
+ Not included in the Gun Kit, only with ref 23
