DeVilbiss Pro Lite E - Additional Parts and Service Tools; Service Parts and Tool Kit Contents; Electrical Grounding Requirement

EN
+
-
1
REF.
PART No.
DESCRIPTION
QTY.
-
-
1
1
1
1
1
SERVICE PARTS
-
-
SN-419-K
SN-406
VALVE ADJUSTING KNOB
SEAL
LOCK NUT
FLUID INLET
52
+ 53
The spray gun must be earthed to dissipate any electrostatic charges which may be created by fluid or
air flows. This can be achieved through the spray gun mounting, or conductive air/fluid hoses.
Electrical bond from the spray gun to earth should be checked and a resistance of less than 10⁶ Ohms
is required.
WARNING
47
-
-
CIRCLIP (KIT OF 5)
VALVE HEAD
WASHER
1
1
1
1
25746-007-K5
-
PARTS LIST CONTINUED
43
44
45
46
48
49
50
51
VALVE BODY
AIR VALVE SERVICE TOOL
1
FLUID INLET KIT
TOOL KIT
NOT INCLUDED IN THE GUN KIT, ONLY WITH REF 23
PRO-470
GTI-428-K5
SPRAY GUN REPAIR KIT (INCLUDES ITEMS MARKED *)
SEAL AND PIN KIT, KIT OF 5 (ITEMS 12, 14 & 15)
SB-E-2-855 R1.0
8/24
