2. Connect the fluid supply hose to fluid inlet connector.
3. Mix coating material to Manufacturer's instructions and strain material.
10. The pattern size can be reduced by turning spreader valve knob (16) clockwise.
11. Hold gun perpendicular to surface being sprayed. Arcing or tilting may result in uneven coating.
12. The recommended spray distance is 150-200mm.
If quick connect couplings are required, use only high flow quick connects. Other types will not flow
enough air for correct gun operation.
Depending on hose length, larger I.D. hose may be required. Install an air gauge at the gun handle.
When gun is triggered on, adjust regulated pressure as required. Do not use more pressure than is
necesarry to atomise the material being applied. Excess pressure will create additional overspray and
reduce transfer efficiency.
14. Always turn off air supply and relieve pressure when gun is not in use.
13. Spray edges first. Overlap each stroke a minimum of 75%. Move gun at a constant speed.
9. If finish is too wet, reduce fluid flow by turning fluid adjusting knob (28) clockwise. If atomisation is
too coarse, increase air inlet pressure. If too fine, reduce inlet pressure.
1. Connect the gun to a clean, moisture and oil free air supply using a conductive hose of at least
8mm I.D.
4. Turn fluid adjusting knob (28) clockwise to prevent fluid needle movement.
5. Turn spreader valve adjusting knob (16) counter clockwise to fully open.
6. Adjust inlet air pressure if required.
7. Turn fluid adjusting knob counter clockwise until first thread shows.
8. Test spray. If the finish is too dry, reduce airflow by reducing air inlet pressure.
