DeVilbiss Pro Lite E - Spray Gun Maintenance and Cleaning Procedures; Methods for Cleaning Components; Disassembly and Assembly Guide; Key for Disassembly Instructions

EN
(reverse for assembly)
Order for disassembly
- see over page
Item Number
- see over page
KEY
SPRAY GUN DISASSEMBLY / ASSEMBLY
SPRAY GUN MAINTENANCE & CLEANING
To clean air cap and fluid tip, brush exterior with a stiff bristle brush. If necesarry to clean cap holes,
use a broom straw or toothpick if possible. If a wire or hard instrument is used, extreme care must be
taken to prevent scratching or burring of the holes which will cause a distorted spray pattern.
To clean fluid passages, remove excess material, then flush with gun wash solution. Wipe the gun
exterior with a dampened cloth. Never completely immerse in any solvent or cleaning solutions as this
is detrimental to the lubricants and life of the spray gun.
#
#
