Devolo dLAN 200 AVmini User Manual

21 Security in the dLAN
devolo dLAN 200 AVmini
dLAN devices in your network in order to form a closed
dLAN network.
You will need the 16-character Security IDs of the va-
rious adapters from the label on the housing. Enter the
code without hyphens in the 4 text boxes and confirm
by clicking Define password. If a security ID is correct
and the device is reachable in the dLAN, the device is
added to the list of already configured adapters.
When launching the dLAN Configuration Wizard again
after a successful initial installation—when integra-
ting a new adapter into the network, for example—
the application will remember devices and security
IDs entered in previous sessions if you have encryp-
ted them with a personal network password or the
default password. In this case, you do not need to
enter the devices again.
However, if the random password was used to encrypt
the network during the last installation, if you want to
fig. 8

Devolo dLAN 200 AVmini Specifications

General

Modulation	BPSK, OFDM, QPSK
Ethernet LAN	Yes
Maximum data transfer rate	200 Mbit/s
Maximum operating distance	300 m
Supported network protocols	TCP/IP
Connectivity technology	Wired
Ports quantity	1
Power supply type	AC
Power requirements	100-240 V, 50/60 Hz
Compliance industry standards	IEEE 802.3, IEEE 802.3x, IEEE 802.3u
Compatible operating systems	Windows XP 32bit, Windows Vista 32/64bit, Windows 7 32/64bit, Linux, Mac OS X & TCP / IP
Power consumption (typical)	2.9 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Internal	No
Certification	EN 55022 EN 50412 EN 60950
Product color	White

Weight and Dimensions

Depth	29 mm
Width	58 mm
Height	90 mm
Weight	103 g
Package weight	510 g
