Devolo dLAN 200 User Manual

Initial use 13
devolo dLAN 200 AV USB extender
3.3 Functions
The dLAN 200 AV USB extender has three control
lamps (LEDs) as well as a USB port and the encryption
button.
Power
Flashes green during start-up of the
dLAN200AVUSBextender; lights up green when the
dLAN 200 AV USB extender is ready for operation.
dLAN
Lights up green when there is a dLAN connection;
flashes during data transfer.
USB
Lights up green when there is a connection to the USB
device; flashes during data transfer.
USB connection
This is where you connect the
dLAN 200 AV USB extender to a USB device using a
USB cable.
Encryption button
Network encryption at the touch of a button; for a
functional description of the encryption button, please
continue reading in chapter 4.2.2 Encrypting a net-
work at the touch of a button.
3.4 Software installation
3.4.1 Software for Windows
Use the installation wizard to install the devolo soft-
ware dLAN Cockpit for using the
dLAN200AVUSBextender with the Windows operat-
ing system:
dLAN Cockpit finds all reachable dLAN adapters in
your dLAN 200 AV network, displays information
about these devices and encrypts your dLAN 200 AV
network individually. In addition, you control access to
the shared USB devices in your dLAN network using
the dLAN Cockpit.
햲 To install the software, insert the included CD-
ROM in the CD drive of your computer. If auto-
play is installed on your computer, the installation
will start automatically. Otherwise, open the
folder with the Windows Explorer by right-clicking
on Start (or the Windows logo) and selecting
Explorer from the context menu. Double-click to
start the installation wizard manually. Then select
the option Install
dLAN 200 AV USB extender.
햳 You can find the installed software applications in
the Start 쒁 All Programs 쒁 devolo program
group.

Devolo dLAN 200 Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	3
Chipset	-
Internal	No
Product color	White
LED indicators	Yes
Modulation	1024-QAM, 256-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.3x
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Maximum operating distance	300 m
WLAN data transfer rates supported	300 Mbit/s
AC input voltage	230 V
AC input frequency	50 Hz
Dimensions (WxDxH)	110 x 68 x 49 mm
Non-operating relative humidity (non-condensing)	10 - 90 %
Input current	0.13 A
Power consumption (typical)	5.6 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	68 mm
Width	110 mm
Height	49 mm
Weight	200 g
