Devolo dLAN 200 User Manual

24 dLAN network
devolo dLAN 200 AV USB extender
When assigning fixed IP addresses,
please note that they must be in the
same IP address range, since you will
otherwise exclude devices from your
dLAN network (unintentionally).
4.3.2 Highlights of the
dLAN 200 AV USB extender
dLAN Cockpit only ever displays the symbols for possi-
ble actions which can be performed logically as a result
of the current connection status. The statuses of a
dLAN 200 AV USB extender are described below.
The dLAN 200 AV USB extender is free.
The device connected to the
dLAN 200 AV USB extender is currently being used by
no subscribers in the dLAN network. This status is il-
lustrated by the blue USB symbol in the top left-hand
corner of the dLAN200AVUSBextender.

Devolo dLAN 200 Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	3
Chipset	-
Internal	No
Product color	White
LED indicators	Yes
Modulation	1024-QAM, 256-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.3x
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Maximum operating distance	300 m
WLAN data transfer rates supported	300 Mbit/s
AC input voltage	230 V
AC input frequency	50 Hz
Dimensions (WxDxH)	110 x 68 x 49 mm
Non-operating relative humidity (non-condensing)	10 - 90 %
Input current	0.13 A
Power consumption (typical)	5.6 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	68 mm
Width	110 mm
Height	49 mm
Weight	200 g
