dLAN network 25
devolo dLAN 200 AV USB extender
Click on the Connect USB device tab page to access
the dLAN 200 AV USB extender directly. The green
USB symbol in the top left-hand corner of the
dLAN200AVUSBextender signals the now exist-
ing connection to the USB device.
The dLAN 200 AV USB extender is occupied by
your own PC and is released for use.
To release the dLAN 200 AV USB extender for use by
the other subscribers in the dLAN network, click on the
Disconnect USB device tab page. The blue USB
symbol in the top left-hand corner of the
dLAN200AVUSBextender now signals that the
USB device has been released.

Devolo dLAN 200 Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	3
Chipset	-
Internal	No
Product color	White
LED indicators	Yes
Modulation	1024-QAM, 256-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.3x
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Maximum operating distance	300 m
WLAN data transfer rates supported	300 Mbit/s
AC input voltage	230 V
AC input frequency	50 Hz
Dimensions (WxDxH)	110 x 68 x 49 mm
Non-operating relative humidity (non-condensing)	10 - 90 %
Input current	0.13 A
Power consumption (typical)	5.6 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	68 mm
Width	110 mm
Height	49 mm
Weight	200 g
