Devolo dLAN 200 User Manual

26 dLAN network
devolo dLAN 200 AV USB extender
The dLAN 200 AV USB extender is already occu-
pied by another computer in the network.
The dLAN 200 AV USB extender is currently being
used by another subscriber in the dLAN network. The
red USB symbol in the top left-hand corner of the
dLAN200AVUSBextender signals this occupied
connection to the USB device.
Request another user to release the USB device by
clicking on the Take over USB device tab page. The
request you have sent is displayed on your screen:
The other user now has the opportunity to accept or
decline your request:
쎲 If the other user accepts your request, you will
automatically be connected with the
dLAN200AVUSBextender. The green USB
symbol in the top left-hand corner of the
dLAN200AVUSBextender signals the now
existing connection to the USB device.

Devolo dLAN 200 Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	3
Chipset	-
Internal	No
Product color	White
LED indicators	Yes
Modulation	1024-QAM, 256-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.3x
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Maximum operating distance	300 m
WLAN data transfer rates supported	300 Mbit/s
AC input voltage	230 V
AC input frequency	50 Hz
Dimensions (WxDxH)	110 x 68 x 49 mm
Non-operating relative humidity (non-condensing)	10 - 90 %
Input current	0.13 A
Power consumption (typical)	5.6 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	68 mm
Width	110 mm
Height	49 mm
Weight	200 g
