19 Initial use
devolo Magic 2 LAN
1-1
3.3 Connecting the
devolo Magic 2 LAN
1-1
CAUTION! Damage to the device caused
by ambient conditions
Only use device indoors in dry conditions
In the following sections we describe how to
connect the devolo Magic 2 LAN
1-1
and integrate
it into a network. We clarify the exact procedures
based on potential network scenarios.
For the permitted voltage range for operating
the device and the power consumption, refer to
the type plate on the rear of the device. For ad-
ditional technical information on our products,
refer to the product area at www.devolo.com
.
3.3.1Starter Kit – Automatic set-up for a
new devolo Magic network
1 Connect one devolo Magic 2 LAN
1-1
to your
Internet access device's network connection
(e.g. your Internet router).
2 Connect the other devolo Magic 2 LAN
1-1
to
the network connection of your computer or
another network device using a network cable.
CAUTION! Tripping hazard
Lay the network cable in a barrier-free
manner and ensure that the electrical
socket and the connected network de-
vices are easily accessible
3 Plug both devolo Magic adapters into available
power sockets within 3 minutes. As soon as the
LEDs on both adapters flash white at regular
intervals of 0.5 sec., they are ready to operate
and automatically start the process of establis-
hing an encrypted connection to each other
(see Chapter 2.3.1 Reading the indicator
light).
If the LEDs on both devolo Magic adapters
light up in white, then your
devolo Magic network has been set up ac-
cording to your individual specifications
and is protected from unauthorised access.

Devolo Magic Series Specifications

General

Type	Powerline adapter
MIMO	Yes
Operating Voltage	100-240 V
Operating Frequency	50/60 Hz
WiFi Standard	IEEE 802.11ac
Maximum Speed	1200 Mbps
Ports	1 Gigabit Ethernet
Encryption	128-bit AES
Standards	IEEE 802.3
Frequency Band	2.4 GHz / 5 GHz
