Devolo Magic Series User Manual

33 Appendix
devolo Magic 2 LAN
1-1
5 Appendix
5.1 Technical specifications
5.2 Bandwidth optimization
To significantly improve the transmission capacity
of the network, we recommend that you comply
with the following "connection rules":
b Plug the devolo Magic 2 LAN
1-1
directly into a
wall socket. Avoid using power strips. This may
impair the transmission of the PLC signals.
b If there are several sockets in the wall directly
next to each other, they behave like a power
strip. Individual sockets are optimal.
Security 128 Bit AES
Device port 1x RJ45
(Gigabit Ethernet port)
Power consumption Maximum: 4.8 W
Typical: 2.8 W
Stand-by: 0.7 W
Power supply internal
196-250 V AC
50 Hz
Temperature
(Storage/Operating
-25°C to 70 °C / 0°C to
40°C
Dimensions (in mm,
without plug)
133x66x42 (HxWxD)
Ambient conditions 10-90% Humidity,
non-condensing
Certifications CE
Fig. 3: Bandwith optimization

Devolo Magic Series Specifications

General

Type	Powerline adapter
MIMO	Yes
Operating Voltage	100-240 V
Operating Frequency	50/60 Hz
WiFi Standard	IEEE 802.11ac
Maximum Speed	1200 Mbps
Ports	1 Gigabit Ethernet
Encryption	128-bit AES
Standards	IEEE 802.3
Frequency Band	2.4 GHz / 5 GHz
