39
ENGLISH
FLIP-OVER SAW D27107, D27107XPS
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough product
development and innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical data
D27107 D27107XPS
Voltage V 230 230
Type 5 3
(D27107 with
worklight LED)
Power input W 2000 2000
Power output W 1080 1080
Max. blade speed min
-1
4000 4000
Blade diameter mm 305 305
Blade bore mm 30 30
Blade body thickness mm 2.1 - 2.2 2.1 - 2.2
Riving knife thickness mm 2.5 2.5
Automatic blade brake time s < 10 < 10
Weight kg 42 42
Cutting capacities
Mitre saw mode
Mitre (max. positions) left 48° 48°
right 48° 48°
Bevel (max. positions) left 48° 48°
right 2° 2°
Max. crosscut capacity at 90°/90° mm
205 x 63
205 x 63
Max. mitre cut capacity at 45° mm 160 160
Max. depth of cut 90° mm 90 90
Max. depth of bevel cut 45° mm 60 60
Max. depth of cut at 45° bevel, 45° mitre mm 60 60
Saw bench mode
Max. ripping capacity left/right mm 120/320 120/320
Depth of cut at 90° mm 81 81
Depth of cut at 45° mm 56 56
L
PA
(sound pressure) dB(A) 95.0 95.0
K
PA
(sound pressure uncertainty) dB(A) 3.0 3.0
L
WA
(sound power) dB(A) 106.0 106.0
K
WA
(sound power uncertainty) dB(A) 3.0 3.0
Vibration total values (triax vector sum) determined according to EN 61029:
Vibration emission value a
h
a
h
=
m/s²
2.1 2.1
Uncertainty K = m/s² 1.5 1.5
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN 61029
and may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure.
WARNING: The declared vibration emission level represents
the main applications of the tool. However if the tool is used
for different applications, with different accessories or poorly
maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working
period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may
significantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and
the accessories, keep the hands warm, organisation of work
patterns.
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
NOTE: This device is intended for the connection to a power supply system
with maximum permissible system impedance Zmax of 0.28 at the
interface point (power service box) of user’s supply.
The user has to ensure that this device is connected only to a power system
which fulfils the requirement above. If necessary, the user can ask the public
power supply company for the system impedance at the interface point.
Defi nitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
D27107/D27107XPS
D
EWALT declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN 61029-1, EN 61029-2-11.
These products also comply with Directive 2004/108/EC and 2011/65/EU.
For more information, please contact D
EWALT at the following address or
refer to the back of the manual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of D
EWALT.
Horst Grossmann
Vice President Engineering and Product Development
DEWALT, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
01.12.2011
