10
ENGLISH
- Fire hazard due to extreme dust concentration when not cleaned
regularly.
- Risk of uncontrolled situations when used in ambient temperatures below
-10 °C or above +45 °C.
The following factors are of influence to noise production:
- the material to be cut
- the type of saw blade
- the feed force
The following factors are of influence to dust exposure:
- worn saw blade
- dust extractor with air velocity less than 20 m/s
- workpiece not exactly guided
Markings on Tool
The following pictograms are shown on the tool:
Safe use warning
Read the instruction manual before use
When using in bench saw mode, ensure upper and lower guards
are in place and well functioning. Never operate the machine
when the bench table is not in horizontal position.
When using in mitre saw mode, make sure that the upper guard
is in place and functioning properly. Ensure the bench saw table
is in its highest position.
When making a sliding cut in mitre saw mode, observe the
instructions as provided under Performing a sliding cut.
Carrying point.
DATE CODE POSITION (FIG. A2)
The Date Code (76), which also includes the year of manufacture, is printed
into the housing.
Example:
2010 XX XX
Year of Manufacture
Package Contents
The package contains:
1 Table top mitre saw
1 Saw blade
1 Parallel rip fence
1 Upper blade guard
1 Push stick
1 Dust collection port (fig. V)
1 T30 star wrench
1 T40 star wrench
1 Instruction manual
1 Exploded drawing
• Check for damage to the tool, parts or accessories which may have
occurred during transport.
• Take the time to thoroughly read and understand this manual prior to
operation.
Description (fi g. A1 - A6)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury could result.
Fig. A1
1 On/off switch
2 Operating handle
3 Head lock up release lever
4 Additional saw bench table locking knob
5 Moveable front lower blade guard
6 Fence right-hand side
7 Fixed table
8 Kerf plate
9 Mitre latch
10 Mitre lever
11 Rotating table/mitre arm
12 Mitre scale
13 Fence left-hand side
14 Bevel scale
15 Bevel clamp handle
16 Saw bench table locking knob
17 Head lock down pin
18 Rail lock knob
Fig. A2
19 Saw bench table
20 Riving knife
21 Upper blade guard
22 Parallel rip fence
23 Push stick location
24 Moveable rear lower blade guard
25 Attachment mounting holes
26 Hand indentation
76 Date code
Optional accessories
Fig. A3
27 Material clamp
Fig. A4
28 Legstand
INTENDED USE
Your D27111/D27112 table top mitre saw has been developed for
professional applications. This high precision machine can be easily and
quickly set to crosscut, bevel, mitre, or compound mitre.
This unit is designed for use with a nominal blade diameter 305 mm carbide
tip blade for professional applications.
DO NOT use under wet conditions or in presence of flammable liquids or
gases.
These table top mitre saws are professional power tools.
DO NOT let children come into contact with the tool. Supervision is required
when inexperienced operators use this tool.
WARNING! Do not use the machine for purposes other than
intended.
