DeWALT DCBL722 - Shipping Mode
Example of Use and Shipping Label Marking
USE: 120 Wh Shipping: 3 x 40 Wh
For example, the Shipping Wh rating might indicate 3 x 40 Wh, meaning 3 batteries of 40 Watt-hours each. The Use
Wh rating might indicate 120 Wh (1 battery implied).
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
The fuel gauge is an indication of approximate levels of charge remaining in the battery pack according to the
following indicators:
75–100% charged
51–74% charged
< 50% charged
The pack needs to be charged
To actuate the fuel gauge, press and hold the fuel gauge button. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level of charge in the battery is below the usable limit, the
fuel gauge will not illuminate and the battery will need to be recharged.
DeWALT DCBL722 - the battery
NOTE: The fuel gauge is only an indication of the charge left on the battery pack. It does not indicate tool
functionality and is subject to variation based on product components, temperature, and end-user application.
For more information regarding fuel gauge battery packs, please call 1-800-4-DeWALT (1-800-433-9258) or visit our
website www.dewalt.com.
The RBRC® Seal
