Volts The total length of Cord in Feet (meters)
120 V 25 (7.6) 50 (15.2) 100 (30.5) 150 (45.7)
240 V 50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)
Ampere Rating
American Wire gauge
More
Than
not
More
Than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
Do not place any object on top of the charger or place the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat. Place the charger in a position away from any heat
source. The charger is ventilated through slots in the top
and the bottom of the housing.
Do not operate the charger with a damaged cord or plug.
Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any
way. Take it to an authorized service center.
Do not disassemble the charger; take it to an authorized service center when service or repair is
required. Incorrect reassembly may result in a risk of electric shock, electrocution, or fire.
Disconnect the charger from the outlet before attempting any cleaning. This will reduce the risk ofelectric
shock. Removing the battery pack will not reduce this risk.
NEVER attempt to connect 2 chargers together.
The charger is designed to operate on standard 120V household electrical power. Do not attempt to touse
it on any other voltage. This does not apply to the vehicular charger.
WARNING: Shock hazard. Do not allow any liquid to get inside the charger. Electric shock may result.
WARNING: Burn hazard. Do not submerge the battery pack in any liquid or allow any liquid to enter the
battery pack. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks
or cracks, return to a service center for recycling.
CAUTION: Burn hazard. To reduce the risk of injury, charge only DeWALT rechargeable battery packs. Other
types of batteries may overheat and burst to result in personal injury and property damage.
NOTICE: Under certain conditions, with the charger plugged into the power supply, the charger can be shorted by
foreign material. Foreign materials of a conductive nature, such as, but not limited to, grinding dust, metal chips, steel
wool, aluminum foil, or any buildup of metallic particles should be kept away from the charger cavities. Always unplug
the charger from the power supply when there is no battery pack in the cavity. Unplug the charger before attempting
to clean.
Charging a Battery (Fig. C)
1. Plug the charger into an appropriate outlet before inserting the battery pack.
2. Insert the battery pack 6 into the charger, making sure the battery pack is fully seated in the charger. The red
(charging) light will blink continuously indicating that the charging process has started.
3. The completion of the charge will be indicated by the red light remaining ON continuously. The battery pack is
fully charged and may be used at this time or left in the charger. To remove the battery pack from the charger,
push the battery release button 5 on the battery pack and then slide the battery pack out of the charger.
