ENGLISH
10
Attaching Quick Connect Suction Hose
Filter to the Suction Hose (Fig. F)
This power cleaner must be used with the quick connect
adapters. The suction hose can only be attached after the
quick connect suction hose filter
10
isinstalled. Use the
suction hose to pull water from a bucket or other fresh
watersource.
NOTICE: Do not use to suction soap, chemicals, dirty or
corrosive liquids, such as window cleaner, plant food,
fertilizers or bleach. Do not use saltwater.
1. To connect the quick connect suction hose filter
10
to
the suction hose
19
, place the end of the quick connect
suction hose filter
10
into the quick connection
22
and
push it firmly onto quick connect suction hose filter
10
.
NOTE: Before use, gently tug on the quick connect
suction hose filter
10
to ensure the connection
issecured.
Attaching the Suction Hose to the Water
Inlet (Fig. G)
Use the suction hose
19
to pull water from a bucket or other
fresh watersource.
NOTICE: Do not use to suction soap, chemicals, dirty or
corrosive liquids, such as window cleaner, plant food,
fertilizers or bleach. Do not use saltwater.
1. To connect the quick connection
22
to the water
intake
7
, push the quick connection
22
firmly onto the
Assembling Spray Wand (Fig. E)
1. To connect the spray wand
11
to the power cleaner
unit
6
, insert the threaded end of the spray wand
11
onto the threaded end of the power cleaner unit
6
. Rotate
the spray wand
11
clockwise until fullytightened.
SPECIFICATIONS
Maximum Pounds per Square Inch 1000
Rated Gallons per Minute 1.0
Battery 60V DC
Inlet Hose 20 ft (6 m)
Pressure of Inlet Water 20-100 PSI
Inlet Water Cold Tap
Soap Consumption Rate 10% MAX
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
Wall Mounting
Some DeWALT chargers are designed to be wall mountable
or to sit upright on a table or work surface.If wall mounting,
locate the charger within reach of an electrical outlet, and
away from a corner or other obstructions which may impede
air flow. Use the back of the charger as a template for the
location of the mounting screws on the wall. Mount the
charger securely using drywall screws (purchased separately)
at least 1” (25.4mm) long, with a screw head diameter of
0.28–0.35” (7–9mm), screwed into wood to an optimal
depth leaving approximately 7/32” (5.5 mm) of the screw
DCB118 and DCB1112 Chargers
The DCB118 and DCB1112 chargers are equipped with
an internal fan designed to cool the battery pack. The fan
will turn on automatically when the battery pack needs to
becooled.
Never operate the charger if the fan does not operate
properly or if ventilation slots are blocked. Do not permit
foreign objects to enter the interior of thecharger.
Electronic Protection System
Li-ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deep discharge. The tool will automatically
turn off and the battery pack will need to berecharged.
Important Charging Notes
1. Longest life and best performance can be obtained if
the battery pack is charged when the air temperature
is between 65° F – 75° F (18° C– 24° C). DO NOT charge
when the battery pack is below 40° F (4.5° C), or above
104° F (40° C). This is important and will prevent serious
damage to the batterypack.
2. The charger and battery pack may become warm to the
touch while charging. This is a normal condition, and
does not indicate a problem. To facilitate the cooling of
the battery pack after use, avoid placing the charger or
battery pack in a warm environment such as in a metal
shed or an uninsulatedtrailer.
3. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp
or other appliance;
b. Check to see if receptacle is connected to a light
switch which turns power off when you turn out
thelights;
c. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
4. You may charge a partially used pack whenever you
desire with no adverse effect on the batterypack.
Charger Cleaning Instructions

WARNING:Shock hazard. Disconnectthe charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using
a cloth or soft non‑metallic brush. Do not use water or
any cleaningsolutions.
